March 2018
Aussie Eco-Clean
AB Scud Cadet Series
OPERATOR'S INSTRUCTION MANUAL
Models:
AB Scud 30
AB Scud 40
Operators must read this manual and
understand it before operating this machine
Australian Pump Industries
Aussie AB Scud Cadet Series ... Operation & Maintenance Manual
www.aussiepumps.com.au
Aussie Pumps
March 2018
REF: ABSCMK1SERIES_2018/1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Aussie Pumps Eco-Clean AB Scud Cadet Series
Summary of Contents for Aussie Pumps Eco-Clean AB Scud Cadet Series
- Page 1 March 2018 Aussie Pumps Aussie Eco-Clean March 2018 AB Scud Cadet Series OPERATOR’S INSTRUCTION MANUAL Models: AB Scud 30 AB Scud 40 Operators must read this manual and understand it before operating this machine Australian Pump Industries REF: ABSCMK1SERIES_2018/1 Aussie AB Scud Cadet Series … Operation & Maintenance Manual...
-
Page 2: Table Of Contents
March 2018 Aussie Pumps AUSSIE ECO CLEAN AB SCUD CADET SERIES OPERATING & MAINTENANCE INSTRUCTIONS GUARANTEE … EXCLUSIVE 4 YEAR PUMP + 3 YEAR ENGINE WARRANTY (HONDA ONLY) This Aussie Eco Clean product is guaranteed against N.B. Warranty is not transferrable to third parties in faults in manufacture for two years from purchase. -
Page 3: Safety Precautions
March 2018 Aussie Pumps SAFETY PRECAUTIONS - IMPORTANT DO NOT direct the spray jet at any person or 10. DO NOT pull the hose over sharp objects. animal. Keep hands and feet clear of the 11. DO NOT attempt to disconnect any hose or cleaning nozzle at all times. -
Page 4: Assembly & Preparation For Use
Securely clamp the hose reel mounting bar across the top of the Scud frame using the two sets of nuts and bolts supplied (AB40 only). Aussie Pumps recommends using Loctite on the bolts to prevent them vibrating loose. 1. Check the oil in the pump. -
Page 5: B: Hose Connections
March 2018 Aussie Pumps Connect whip hose to high pressure outlet on other end of the tube, with the strainer attached, pump. in the chemical container (not supplied). 3. Connect gun/lance assembly to high pressure hose. 4. Check inlet water filter is clean then connect water supply hose to machine. -
Page 6: C: Before Starting
March 2018 Aussie Pumps Before starting the machine 5. Start engine, pull the recoil starter grip lightly until resistance is felt, then pull briskly. OPERATE IN WELL VENTILATED AREAS ONLY. 6. After engine starts, release the gun trigger and 1. Ensure machine is level slowly open the choke. -
Page 7: F: Applying Detergent
March 2018 Aussie Pumps NOTE: Check the system for water leaks, fuel leaks, 4. Spray angle can be adjusted by rotating the nozzle cover. The amount of foam delivered is adjusted oil leaks, hose kinks, etc. Correct any problems before with the knob on top. -
Page 8: Care & Maintenance
March 2018 Aussie Pumps Warning: check nozzles and replace of worn If pressure drops off, check nozzle for wear. Nozzles should be replaced on a regular basis (every month for machines in regular use, every 3 months for machines used intermittently. Using the machine with the incorrect nozzle size or worn nozzle will void warranty and can be dangerous to the operator. -
Page 9: Troubleshooting Guide
March 2018 Aussie Pumps TROUBLE SHOOTING GUIDE FAULT CAUSE REMEDY Pump sucking air Check water supply and possibility of air ingress. Check and clean or replace if necessary Valves sticking Pump running normally but Check and replace Unloader valve seat faulty... -
Page 10: Parts Identification
March 2018 Aussie Pumps PARTS IDENTIFICATION AB30 Model Engine Pump Pump Flow Frame style Pump Model Pressure rate (psi) (lpm) AB Scud 30 Honda GX200 6.5HP WBXG3025 3100 4785 Four wheel full frame 3200 AB Scud 40 Honda GX390 13HP... -
Page 11: Replacement Parts
March 2018 Aussie Pumps REPLACEMENT PARTS AB Scud Position Part No Description Nozzles C915030M HP NOZZLE (15° ANGLE, TIP SIZE 30) A & B C915500MSS LP DETERGENT NOZZLE Lance C4723.45.115 VARIO LANCE C3924.01 684MM SS DOUBLE LANCE C/W BOOT M4021108007 AL13 GUN WITH MELTED HANDLE&... -
Page 12: Pump Parts
March 2018 Aussie Pumps PUMP PARTS WBXG3025 (AB30) (KIT 82 - WBG2525) Kit No. Part No. Description B049840973 Seal Kit Major (21 pieces) B049843973 Seal Kit Minor (15 pieces) 169 (WGXG3025) B049963973 Oil seal kit (8 pieces) 82 (WBG2525) B049846973... - Page 13 March 2018 Aussie Pumps PUMP PARTS TMG4035 (AB Scud 40) Kit No. Part No. Description B069867973 VALVE KIT B079806973 SEAL KIT MINOR B079804973 SEAL KIT MAJOR B049837973 OIL SEAL KIT Item 25 B040120322 OIL SIGHT GLASS Item 29 B049832973 OIL FILLER PLUG...
-
Page 14: Blaster Risk Assessment
March 2018 Aussie Pumps AUSSIE HIGH PRESSURE BLASTER RISK ASSESSMENT MODELS: RISK RANKING METHOD: In line with the National Occupation Health & Safety Risk is the combination of the likelihood of a specific Commission’s requirements the data below applies to... - Page 15 March 2018 Aussie Pumps POTENTIAL HAZARD: Risk Hazard Risk Controls Rating Entanglement with hose Personal injury of the Warning stickers (tripping, falling) operator or bystanders hose reel option Warning notice on blaster Warning in Operator’s Manual,...
-
Page 16: Warnings
March 2018 Aussie Pumps WARNINGS OVERSPEEDING HIGH PRESSURE SETTING Do not operate machine at over 3200rpm The high pressure pump is factory set to (engine speed). Over speeding can cause operate at its rated pressure. DO NOT ADJUST. serious pump damage.
