- Page 1 OPERATION & PARTS MANUAL MODEL QP60TDK SERIES TRASH PUMP (KUBOTA D1105 DIESEL ENGINE) Revision #0 (Sept 2018) THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.
- Page 2 PAGE 2 QP60TDK SERIES TRASH PUMP• OPERATION AND PARTS MANUAL — REV. #0...
-
Page 3: Table Of Contents
Check engine battery and cable connections. 5 Hardware and damage check. 6 Check vacuum pump seal oil. 7 Check bearing housing oil level. 8 Check pump seal. QP60TDK SERIES TRASH PUMP• OPERATION AND PARTS MANUAL — REV. #0 PAGE 3... -
Page 4: Safety
ALWAYS wear approved respiratory You CAN be KILLED or SERIOUSLY INJURED if you protection when required CAUTION You CAN be INJURED if you DO NOT follow these PAGE 4 QP60TDK SERIES TRASH PUMP• OPERATION AND PARTS MANUAL — REV. #0... - Page 5 CAUTION—EYE & HEARING HAZARDS ALWAYS wear approved eye and hearing protection when required. QP60TDK SERIES TRASH PUMP• OPERATION AND PARTS MANUAL — REV. #0 PAGE 5...
-
Page 6: Rules And Regulations
Rotating parts can cause injury if ALWAYS check the equipment for loosened threads or contacted bolts before starting. PAGE 6 QP60TDK SERIES TRASH PUMP• OPERATION AND PARTS MANUAL — REV. #0... - Page 7 Failure to maintain water inside the pump housing will cause severe damage to the pump. In winter drain water from pump housing to prevent freezing. QP60TDK SERIES TRASH PUMP• OPERATION AND PARTS MANUAL — REV. #0 PAGE 7...
- Page 8 The battery contains combustible gases and liquids. If these gases and liquids come in contact with a flame or spark, an explosion could occur. PAGE 8 QP60TDK SERIES TRASH PUMP• OPERATION AND PARTS MANUAL — REV. #0...
-
Page 9: Parts List
PARTS LIST PARTS LIST & EXPLODED DRAWING (QP60TD) PART 1 QP60TDK SERIES TRASH PUMP• OPERATION AND PARTS MANUAL — REV. #0 PAGE 9... - Page 10 PARTS LIST PARTS LIST & EXPLODED DRAWING (QP60TD) PART 2 PAGE 10 QP60TDK SERIES TRASH PUMP• OPERATION AND PARTS MANUAL — REV. #0...
- Page 11 PARTS LIST PARTS LIST & EXPLODED DRAWING (QP60TD) PART 3 QP60TDK SERIES TRASH PUMP• OPERATION AND PARTS MANUAL — REV. #0 PAGE 11...
- Page 12 PARTS LIST PARTS LIST & EXPLODED DRAWING (QP60TD) PART 4 PAGE 12 QP60TDK SERIES TRASH PUMP• OPERATION AND PARTS MANUAL — REV. #0...
-
Page 13: Specifications
1850 x 1165 x 1880 ( mm ) in wooden crate 20 Net Weight 680 kg Gross Weight ( in package ) 790 kg 22 Standard paint Pump: Orange Steel base: Black QP60TDK SERIES TRASH PUMP• OPERATION AND PARTS MANUAL — REV. #0 PAGE 13... - Page 14 This product does not have an electrical works equipped with the preservation parts such as brakes, blinker. Please use the traction equipment as assistance to move a pump in operation-fields PAGE 14 QP60TDK SERIES TRASH PUMP• OPERATION AND PARTS MANUAL — REV. #0...
-
Page 15: Outer Dimensions
OUTER DIMENSIONS QP60TDK SERIES TRASH PUMP• OPERATION AND PARTS MANUAL — REV. #0 PAGE 15... -
Page 16: Indicator Light (Control Box)
Engine stopped immediately by pushing down button in an emergency. apply button To release, return the ignition to “OFF” position and turn emergency button in direction of arrow on button. PAGE 16 QP60TDK SERIES TRASH PUMP• OPERATION AND PARTS MANUAL — REV. #0... -
Page 17: General Information
Elevations over 3,000 feet will effect the performance of the pump. Due to less atmospheric pressure at higher altitudes, pumps DO NOT have the priming ability that they have at sea level. QP60TDK SERIES TRASH PUMP• OPERATION AND PARTS MANUAL — REV. #0 PAGE 17... -
Page 18: Applications
Total Dynamic Head - The Dynamic Head Suction lift or head: Head plus the Dynamic Discharge Head. Also referred to as total head. Static Suction Lift - The vertical distance from PAGE 18 QP60TDK SERIES TRASH PUMP• OPERATION AND PARTS MANUAL — REV. #0... -
Page 19: Troubleshooting (Pump)
Impeller does not turn, pump is hard to Adjust clearance by removing shim from behind Impeller and wear plate binding? start. impeller. Defective engine? See Kubota Engine Owners Manual. QP60TDK SERIES TRASH PUMP• OPERATION AND PARTS MANUAL — REV. #0 PAGE 19... - Page 20 Reliable Products … Reliable People Australian Pump Industries Pty Ltd 7 Gladstone Road, Castle Hill NSW 2154 Ph: (02) 02 8865 3500 Fax: (02) 9894 4240 www.aussiepumps.com.au info@aussiepumps.com.au PAGE 20 QP60TDK SERIES TRASH PUMP• OPERATION AND PARTS MANUAL — REV. #0...
