- Page 1 Wall Mounting Procedures ACR120 Contactless Reader/Writer Website: www.acs.com.hk Advanced Card Systems Ltd. Email: info@acs.com.hk...
- Page 2 ACR120 readers with separate PVC stickers. (You will receive the individual PVC stickers at the same time so that after wall mounting, you can put it back to protect the casing.)
- Page 3 A C R 1 2 0 C o n t a c t l e s s R e a d e r / W r i t e r 2. Remove the rubber feet at the back so that you can drive in the screws. 3. Tighten the screws. ACR120 Wall Mounting Procedures Version 1.7 December 2007 Page 3 of 4...
- Page 4 A C R 1 2 0 C o n t a c t l e s s R e a d e r / W r i t e r 3. Tighten the screws (cont’d). 4. Wall mounting is completed. Place the PVC sticker on the front casing to cover the screw holes. ACR120 Wall Mounting Procedures Version 1.7 December 2007 Page 4 of 4...
