2-Port KVM Switch
with Audio Support and Built-In Cabling
Control two computers
using one monitor,
and a USB
keyboard
and mouse

User Manual

F1DL102U

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F1DL102 and is the answer not in the manual?

Questions and answers

Summary of Contents for Belkin F1DL102

  • Page 1: User Manual

    Australia: 1800 666 040 P74475 © 2004 Belkin Corporation. All rights reserved. All trade names are registered trademarks of respective manufacturers listed. Mac OS is a trademark of Apple Computer, Inc., registered in the U.S. and other countries. 2-Port KVM Switch...
  • Page 2: Table Of Contents

    Belkin exemplifies our commitment to delivering high-quality, durable products at a competitive price. Engineered to give you control over multiple computers and/or servers from one console, Belkin KVM switches come in a variety of capacities suitable for all configurations, large or small. A Belkin Three-Year Warranty and free technical support back this Switch.
  • Page 3: Overview

    OVERVIEW The Belkin 2-Port KVM Switch with Audio Support and Built-In Cabling allows you to control multiple computers with one keyboard, monitor, and mouse. The Switch supports USB input devices (keyboard and mouse), VGA, SVGA, XGA, and USB computers. Features Complete Compact Solution Built-in cables and color-coded connectors make operation and organization easy.
  • Page 5: Unit Display Diagram

    OVERVIEW Unit Display Diagram The 2-Port KVM Switch with Audio Support and Built-In Cabling: Push button with LEDs Console Speaker Jack Console USB Port Console VGA Monitor Port Console USB Port Console Mic Jack Specifications Part No.: F1DL102U PCs Supported: 2...
  • Page 6: Installation

    INSTALLATION Pre-Configuration Where to Place the Switch The Switch is designed for positioning on the desktop. The exact placement will be based on the location of your CPUs and length of your cables. Cable Distance Requirements VGA signals are best retained when transmitted up to eight feet. Beyond eight feet, probability of video degradation increases with an increase in distance.
  • Page 7: Faqs

    3. Connect your speaker cable to the green speaker jack on the front panel of your Switch. 4. Connect your mic cable to the pink mic jack on the front panel of your Switch. FAQs Q: What operating system does the Switch support? A: The Switch will support Windows 2000, Me, XP, Linux, and Mac OS X v10.x...
  • Page 8: Troubleshooting

    FAQs Q: What are the benefits of the Belkin 2-Port KVM Switch with Audio Support and Built-In Cabling over a similar competitor product? A: The Belkin 2-Port KVM Switch with Audio Support and Built-In Cabling is an affordable solution, packed with features usually found in higher-priced units.
  • Page 9 TROUBLESHOOTING • Connect the KVM Switch USB cable directly to the USB port on the computer. • Make sure that the drivers for your keyboard are installed on your computers. • Uninstall all other keyboard drivers from your computers. Mouse Mouse is lost when I switch to a different channel.
  • Page 10: Information

    Belkin Corporation warrants this product against defects in materials and workmanship for its warranty period. If a defect is discovered, Belkin will, at its option, repair or replace the product at no charge provided it is returned during the warranty period, with transportation charges prepaid, to the authorized Belkin dealer from whom you purchased the product.
