Hard Wired Heating with Wireless Hot Water
Control, 3 Port Mid-Position Valve
FP715 Programmer
FP715 Programmer
N
L
1
HW OFF
230Vac
10
Room Thermostat
2
3
4
HW ON
HTG ON
HTG OFF
RET1000MS
N
L
2
N
N
L
L SW.L
N
Pump
Boiler
RX1-S Receiver -
paired to CET2000B-RF
2
L
1
3 Port Mid-Position Valve
CET2000B-RF
3
