4. Mechanical Instructions
Index of this chapter:
4.1 Cable Dressing
4.2 Service Positions
4.3 Assy/Panel Removal
4.4 Set Re-assembly
4.1
Cable Dressing
Mechanical Instructions
Figure 4-1 Cable dressing 42" (Frame styling)
Figure 4-2 Cable dressing 47" (Frame styling)
LC9.1A LA
Notes:
•
Figures below can deviate slightly from the actual situation,
due to the different set executions.
4.
EN 9
18490_100_090409.eps
090409
18490_101_090409.eps
090409
2009-Apr-10
