6. Alignments

Index of this chapter:
6.1 General Alignment Conditions
6.2 Hardware Alignments
6.3 Software Alignments
6.4 Option Settings
Note: Figures below can deviate slightly from the actual
situation, due to the different set executions.
General: The Service Default Mode (SDM) and Service
Alignment Mode (SAM) are described in chapter 5. Menu
navigation is done with the CURSOR UP, DOWN, LEFT or
RIGHT keys of the remote control transmitter.
6.1 General Alignment Conditions
Perform all electrical adjustments under the following
conditions:
• Power supply voltage (depends on region):
– AP-NTSC: 120 V
– AP-PAL-multi: 120 - 230 V
– EU: 230 V / 50 Hz (± 10%).
AC
– LATAM-NTSC: 120 - 230 V
– US: 120 V / 60 Hz (± 10%).
AC
• Connect the set to the mains via an isolation transformer
with low internal resistance.
• Allow the set to warm up for approximately 15 minutes.
• Measure voltages and waveforms in relation to correct
ground (e.g. measure audio signals in relation to
AUDIO_GND).
Caution: It is not allowed to use heatsinks as ground.
• Test probe: Ri > 10 Mohm, Ci < 20 pF.
• Use an isolated trimmer/screwdriver to perform
alignments.
6.2 Hardware Alignments
There are no hardware alignments foreseen for this chassis,
but below find an overview of the most important DC voltages
on the SSB. These can be used for checking proper functioning
of the DC/DC converters.
Description Test Point Specifications (V)
+12VS F124
+3V3_STBY F101
+3V3_SW F133
+1V2_SW F131
+5V_SW F132
+1V8_SW F125
+1V0_SW F134
+8V_SW F122
+5VS F228
+VDISP F934
+VTUN F123
+5V_IF F229
+5VTUN F219
6.3 Software Alignments
With the software alignments of the Service Alignment Mode
(SAM) the Tuner and RGB settings can be aligned.
To store the data: Use the RC button "Menu" to switch to the
main menu and next, switch to "Stand-by" mode.
6.3.1 Tuner Adjustment (RF AGC Take Over Point)
Purpose: To keep the tuner output signal constant as the input
signal amplitude varies.
or 230 V / 50 Hz (± 10%).
AC AC
/ 50 Hz (± 10%).
AC
/ 50 Hz (± 10%).
AC
Diagram
Min. Typ. Max.
11.40 12.00 12.60 B01_DC-DC
3.20 3.30 3.40 B01_DC-DC
3.14 3.3 3.46 B01_DC-DC
1.18 1.25 1.31 B01_DC-DC
4.94 5.2 5.46 B01_DC-DC
1.71 1.80 1.89 B01_DC-DC
0.99 1.05 1.10 B01_DC-DC
7.6 8.0 8.4 B01_DC-DC
4.75 5 5.25 B02_Tuner_IF
11.40 12.00 12.60 B04D_LVDS
30 33 36 B01_DC-DC
4.75 5 5.25 B02_Tuner_IF
4.75 5 5.25 B02_Tuner_IF
Alignments LC9.1A LA
The LC9.1A LA chassis comes with the UV1856 analogue
tuner. No alignment is necessary, as the AGC alignment is
done automatically (standard value: "15"). However in case of
problems use the following method (use multimeter and RF
generator):
• Apply a vision IF carrier of 38.9 MHz (105 dBuV = 178
mVrms) to injection point A258 (input via 50 ohm coaxial
cable terminated with an RC network of series 10nF with
120 ohm to ground).
• Measure voltage on pin 1 of the tuner (test point F250).
• Adjust AGC (via SAM menu: TUNER -> AGC), until voltage
on pin 1 is 3.3 +0.5/-1.0 V.
• Store settings and exit SAM.
6.3.2 RGB Alignment
Before alignment, choose "Setup" -> "Picture" and set:
• "Brightness" to "50".
• "Colour" to "50".
• "Contrast" to "100".
White Tone Alignment:
• Activate SAM.
• Select "RGB Align" and choose a colour temperature.
• Use a 100% white screen as input signal and set the
following values:
– All "White point" values initial to "256".
– All "BlackL Offset" values to "0".
In case you have a colour analyser:
• Measure with a calibrated (phosphor- independent) colour
analyser (e.g. Minolta CA-210) in the centre of the screen.
Consequently, the measurement needs to be done in a
dark environment.
• Adjust the correct x,y coordinates (while holding one of the
White point registers R, G or B on "256") by means of
decreasing the value of one or two other white points to the
correct x,y coordinates (see Table 6-1 White D alignment
values). Tolerance: dx: ± 0.004, dy: ± 0.004.
• Repeat this step for the other colour Temperatures that
need to be aligned.
• When finished return to the SAM root menu and press
STANDBY on the RC to store the aligned values to the
NVM.
Table 6-1 White D alignment values
Value Cool (11000 K)
x 0.278
y 0.278
If you do not have a colour analyser, you can use the default
values. This is the next best solution. The default values are
average values coming from production (statistics).
• Set the RED, GREEN and BLUE default values per
temperature according to the values in the "Tint settings"
table.
• When finished return to the SAM root menu and press
STANDBY on the RC to store the aligned values to the
NVM.
Table 6-2 Tint settings 42"
Colour Temp.
Cool
Normal
Warm
6. EN 27
Normal (9000 K) Warm (6500 K)
0.289 0.314
0.291 0.319
R G
246 248 255
255 236 180
210 226 255
2009-Apr-10
B
