- Page 1 Hanover Outdoor Furniture IMPORTANT If you have any problems with this product (missing or damaged parts, assembly issues, etc.), PLEASE DO NOT RETURN TO THE RETAILER/STORE from where you purchased the product. 1‐800‐416‐3511 Please call our Toll‐Free Customer Service Hotline at: Between 9:00 AM and 5:00 PM Eastern Time, Monday through Friday www.hanover‐products.com Or visit our website at: To expedite any future warranty claims, please retain the Instruction Sheet, Warranty Card and receipt for future use. For additional on‐line support on assembly, troubleshooting and care & maintenance of your outdoor furniture, please visit our website at: www.hanover‐products.com. 6/1/2015 (a) ...
- Page 2 ASSEMBLY INSTRUCTIONS Figure 1. Attach the seat frame to the back frame by using four 5/16"x40 mm bolts and washer as shown in Guide these bolts through the holes in the seat frame, into the fixed nuts already in place in the back frame. Do not over tighten Attach love seat arm by inserting two 5/16"x25...
- Page 3 SK0941 SK0942 RIGHT ARM 5/16" X 25 MM BOLT HW0186 5/16" X 40 MM BOLT HW0275 Ø8.5 X 1.5 MM HW0005 WASHER BOLT COVER HW0022 HEX BOLT DRIVER HW0006 FOOT CAP-1 FC0030 FACTORY ASSEMBLY FOOT CAP-2 FC0308 FACTORY ASSEMBLY BGC08006...
- Page 4 ASSEMBLY INSTRUCTIONS ARL11103 CSA Model 98910 Installer: Leave these instructions with consumer. Consumer: Keep these instructions for future reference DANGER WARNING: If you smell gas: Improper installation, adjustment alteration, 1. Shut off gas to the appliance. service or maintenance can cause injury or 2.
-
Page 5: Important Safety Information
IMPORTANT SAFETY INFORMATION The installation must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1/NFPA 54; International Fuel Gas Code. ; Natural Gas and Propane Installation Code, CSA B149.1; or Propane Storage and Handling Code, B149.2, as applicable. The appliance and its appliance main gas valve must be disconnected from the gas supply piping system during any pressure testing of that system at test pressures in excess of 1/2 psi (3.5kPa). -
Page 6: Specifications
IMPORTANT SAFETY INFORMATION ABOUT PROPANE (LP) GAS A self contained LP-gas cylinder for use with this appliance must have a capacity of 20 lbs. and must be equipped with a Type 1 connector and an OPD (overfill protection device). See Figure 1. The LP-gas supply cylinder to be used must be constructed and marked in accordance with the specification for LP-gas cylinders of the U.S. -
Page 7: Parts Identification List
PARTS IDENTIFICATION LIST PART DESCRIPTION PART# CONTROL KNOB FP0245 GAS VALVE FP0307 THERMOCOUPLE FP0004 LP REGULATOR HOSE FP1369 ELECTRODE FP1375 GAS TUBE FP0309 ORIFICE ELBOW FP1385 IGNITION MODULE FP0006 ORIFICE BRACKET FP0311 PROPANE ORIFICE FP1283 NATURAL GAS ORIFICE FP1284 LP TANK RETAINING KNOB FP0585 “AAA”... -
Page 8: Installation
INSTALLATION With the help of another person, turn the table base assembly in the upright position. Carefully place the table top (not included) onto the table base. After making any necessary adjustments to the alignment of the table top and firepit base, use bolts and washers as shown in Figure 3. Guide the bolts through the holes in the base brackets, into the pre-drilled holes in the table top. - Page 9 Remove the cardboard cover from the ignition well as shown in Figure 5. Remove any lava rock or fire ice on top of ignition well. Figure 5 Cardboard Cover 4. Lift off the tank door, place the tank in the holder and use the chain to hold the tank.
-
Page 10: Natural Gas Conversion
NATURAL GAS CONVERSION Natural gas conversion must be performed only by your natural gas provider or service company. 1.Disconnect the regulator hose from the gas valve. See Figure 8. Figure 8 2.Disconnect the gas tube from the orifice elbow. Remove the two M4 nuts and remove the orifice holder. -
Page 11: Lighting Instructions
LIGHTING INSTRUCTIONS 1. Locate the control and igniter panel. Make sure the control knob is in the “OFF” position. See Figure 10. Open the tank door and open the tank valve all the way. 2. Push in the igniter button. You will hear a slight clicking sound. -
Page 12: Troubleshooting Guide
