- Page 1 Arkal 4” Spin Klin Twin Apollo Filtration Battery User Guide Installation and Operation Instructions 4” Twin Apollo 08.2013 Page 1 of 14...
- Page 2 Please note, the filter enters a flushing mode automatically, without prior warning. Use original parts only when servicing the filter. 10. Arkal cannot accept responsibility for any changes or modifications to the equipment. Special Note Before opening the filter lock, check that there is no pressure in the filter.
- Page 3 3. Description and Operation Table of Filtration Degree of the Discs and Color Code Color Code Blue Yellow Black Mesh Micron Spin Klin Spine - The Core of the Spin Klin Filtration System The Spin Klin ® discs are stacked on the Spin Klin ®...
- Page 4 Modes of the filter’s Control valve Filtration Position: Water flows from port [A] (main supply) to port [B] (filter connection). Port [C] (drain water outlet) is closed by the seal. Backwash Position: Command pressure is applied to the diaphragm’s control chamber through port [D]. The diaphragm moves the sealed shaft, port [A] closes, preventing flow to the filter.
- Page 5 Mode of Operation Filtration Process During the filtration process the water flows through the inlet manifold, reaching the filters through the backwash valves. The filtered water flow through the outlet manifold into the system. Backwash Process The backwash process begins with a signal from the control unit activated by the pressure difference between the inlet and outlet or by time.
- Page 6 4. Technical Data - 4" Spin Klin Twin Apollo 3 Units 4 Units 5 Units 6 Units 7 Units 8 Units Max. pressure bar/psi 10/145 10/145 10/145 10/145 10/145 10/145 Min. backwash pressure bar/psi 2/29 2/29 2/29 2/29 2/29 2.0/29 Max.
- Page 7 6. P & ID Control Refer to the manufacturer’s handbook before installing the controller. Make sure that the voltage of both the solenoid unit and controller are correct. Set the manual operation button to automatic. Check that the ∆P hydraulic switch HIGH and LOW pressure lines are correctly connected ...
- Page 8 7. Apollo Spin Klin - System Maintenance Monthly Maintenance Check inlet /outlet pressures: In case the pressure differential is above 5 m / 7 PSI. Activate automatic backwash of the Spin Klin filter battery. In the event that the pressure differential remains high check for possible failures. Check for leakages from the drain manifold: In case there is a leakage of water during the filtration stage, check for possible failure at the backwash valve seals.
- Page 9 Seasonal Maintenance - Discs To guarantee thorough cleaning the following steps should be taken: Close the water inlet after backwashing the systems. Make sure that there is no pressure in the system, pull out the safety Figure 1 Figure 2 pin, open the clamp and remove the cover.
- Page 10 Attention: When carrying out any of the following seasonal maintenance, service, or cleaning the discs – After backwashing the system and after closing the water inlet, make sure that there is no pressure in the system! Please Note: Before removing the cover you may experience the vacuum phenomenon – which will make the removing of the cover very difficult or almost impossible.
- Page 11 If these deposits cannot be eliminated by pretreatment of the water, we recommend the following cleaning procedure: Material and Equipment A well ventilated working place. 2 small containers (1 liter), 2 large containers (15 liter) and a stirring stick, all resistant to chemicals, preferably of polypropylene.
- Page 12 Cleaning Carbonates and Iron Deposits Open the filter and remove the dirty discs. Arrange the discs loosely on the plastic rope. Prepare a 5% Solution of Hydrochloric Acid: 1) Pour 10 liters of water into one of the large containers. 2) Carefully add 2 liters of Hydrochloric Acid (30%) into the water.
- Page 13 8. Troubleshooting No Backwash Operation Check inlet and outlet pressures Check & clean command filter Check controller – manually operate the backwash cycle No command transfer Functioning correctly Some commands do not function Check electrical source Check electrical source Replace battery if needed Replace battery if needed Check solenoid electrical connectors...
- Page 14 Identifying Malfunctions in the Apollo system Continuous or Non-stop Backwashing Continuous backwash Nonstop backwash cycle Disconnect the control Check inlet / outlet pressure pipes from the valves Check pressure differential gauge and replace if needed Check controller described above Contact your local distributor Command transfer No command transfer Disconnect the drain manifold...
