Communication Options

Select "Comm Opt", press [OK], the following appears:
The TQ600
communications.
Baud Rate: The baud rate may be set to 9600, 19200 38400,
57600 & 115200.
Dev Num: The terminal's unique Device Number, the range is
1 to 255.
IP Addr: Defaults to IP address 192.168.1.201
Net Speed: The default Net Speed is "AUTO", the other
options are 10M-F, 10M-H, 100M-F and 100M-H.
Comm. Opt
►Baud Rate
Dev Num
IP Addr
----------------------------
Net Speed
NetMask
Gateway
Ethernet
RS232
RS485
USB
COMM Key
fully supports
- 46 -
▼
115200
1
AUTO
Y
N
N
Y
0
Ethernet, RS232 & USB
