  • Page 1 SUBMERSIBLE WATER PUMP INSTRUCTION MANUAL MODEL HOTLINE 1300 AQUATEC 02EV105 - EV1900 02EV125 - EV2900 VERSION 02EV155 - EV3900 JUNE 2016 02EV175 - EV4900 PMAX EVOII 1900_2900_3900_4900 Pump Instructions.indd 1 7/11/17 7:52 am...
  • Page 2: Technical Specifications

    WELCOME TO THE WORLD OF PONDMAX™. YOU MADE THE RIGHT CHOICE INVESTING IN THIS QUALITY PRODUCT. THANK YOU AND ENJOY. BEFORE USING THIS PRODUCT, PLEASE READ THESE INSTRUCTIONS OF USE CAREFULLY AND MAKE YOURSELF FULLY FAMILIAR WITH THE UNIT. PLEASE KEEP THESE INSTRUCTIONS IN A SAFE PLACE FOR FUTURE REFERENCE.
  • Page 3: Design Highlights

    SUBMERSIBLE WATER PUMPS DESIGN HIGHLIGHTS The PondMAX EvoII Submersible Pumps have been manufactured with advanced technology to provide you with the best quality pumps for your pond or water feature. Visit our website to view our range of pond filtration, outdoor/ underwater lighting, water treatments and general accessories.
  • Page 4: Important Safeguards

    IMPORTANT SAFEGUARDS Please read the operating instructions and familiarise yourself with the equipment before placing it in service. Correct and safe use of the system requires strict compliance with the safety instructions. For safety reasons, persons less than 16 years of age or infirm persons that are not familiar with these instructions should not use this equipment.
  • Page 5: Installation

    SUBMERSIBLE WATER PUMPS INSTALLATION For your convenience we have provided two different front filter cages. One has a built in flow control, that can be used to adjust the water flow if the flow is too fast for a particular installation. This is used in clean waterfeatures, where a “filter-less”...
  • Page 6: Cleaning Instructions

    WATERFEATURE PLUMBING GUIDE If used to supply water to a waterfeature, cascade, waterfall, ect; where a pipe is needed to be used, use the hosetails supplied in the package. • For best results, use the bigger tubing size • Then select the Hose tail. Locate the second O’ring recommended in the table previously.
  • Page 7: Important Notes

    SUBMERSIBLE WATER PUMPS Turn the filter case in the direction as indicated by the arrow, then lift it off. Unclip the snap-fit catch under the base plate, and drawn out in the direction of the arrow. Take off the base plate. To maintain the impellor of the pump, turn the Impellor Cover in an anti-clockwise direction as indicated by the arrow, to the stop position.
  • Page 8: Exploded View

    EXPLODED VIEW Sponge Filter cage. Internal Sponge Pre-filter Insert Flow Adjuster Knob - [EV1900 - EV4900] Front filter Screen - With hole for flow adjuster - [EV1900 - EV4900] Blanking Cap for Hole in Front Filter Screen shown (optional) 1” Threaded Bush - for optional Pre-filter Bio-sponge.
  • Page 9: Spare Parts

    SUBMERSIBLE WATER PUMPS SPARE PARTS EV1900 / EV2900 / EV3900 / EV4900 / PART DESCRIPTION EV-7200 EV-9200 EV-11200 EV-13600 EV1910-DC EV2910-DC EV3910-DC EV4910-DC Sponge Filter cage. 12EV002 Internal Sponge Pre-filter Insert 12EV003 Flow Adjuster Knob - [EV1900 - 12EV004 EV4900] Front filter Screen - With hole for flow 12EV005 adjuster - [EV1900 - EV4900]...
  • Page 10: Troubleshooting

    TROUBLESHOOTING Problem Reason Solution Check that the plug is connected and No Power power point turned on. Sponges and filter media blocked with Clean the sponges and filters. sludge. WATER PUMP Impellor is blocked with sludge or lime Clean the Impellor as per the instructions. NOT WORKING scale build up.
  • Page 11: Extended Warranty

    • Loss of livestock, damage to property or for any claim under this extended warranty. personal injury caused by this product will not • Where Aquatec determines goods are being be covered. used in a manner contrary to the instructions, specifications or this Warranty, Aquatec •...
