Product Description and Specifications

t
e
,
f
Product Features PowerPack
All representations of bike components, with the exception
of the battery packs and their holders, are schematic and
can deviate from your eBike.
1 Holder for the rack-type battery pack
2 Rack-type battery pack
3 Operation and charge-control indicator
4 On/Off button
5 Key for the battery pack lock
s Bosch eBike Systems
6
5
3
11
10
4 3
1
13 12
4
7
6
5
13
12
6 Battery pack lock
7 Upper holder for the standard battery pack
8 Standard battery pack
9 Bottom holder for the standard battery pack
10 Cover lid (Supplied only on eBikes with
2 battery packs)
11 Battery charger
12 Socket for charge connector
13 Charge socket cover
English–6
