  • Page 1 23.6” Full HD Widescreen LED Monitor L236E...

  • Page 2: Getting Started

    1 Getting Started 2 Control Panel/ Back Panel 3 On Screen Display 4 Technical Specs 5 Care & Maintenance 6 Troubleshooting 7 Safety Info & FCC warning...

  • Page 3: Package Includes

    Package includes • AC power cord • VGA cable • Quick Start Guide • Tool Kit AC Power Cord VGA Cable...

  • Page 4: Installation

    Installation Connect power and video cables Power Power on Computer and Monitor...
  • Page 5 Control Panel/Back Panel 100x100mm VESA AC Power Menu Scroll Up Scroll Down Enter/Select Power...

  • Page 6: Using On Screen Display (Osd) Functions

    Using On Screen Display (OSD) Functions Main Menu Button Function To adjust the luminance of the video. Brightness adjust brightness (Between 1-100) increase brightness, decrease brightness To adjust the foreground white level of screen image. Contrast adjust contrast (Between 1-100) increase contrast, decrease contrast.

  • Page 7: View Mode

    Button Function Warm Nature Cool Color Setting User color: Individual adjustments for red (R), green (G), blue (B). User 1. Press button to select the desired color. 2. Press button to adjust selected color. Optimize the H-Position, V-Position, Clock, and Phase (For VGA Auto Adjust to switch On/Off Input only)
  • Page 8 Button Function Language to change OSD language H-Position moves menu left and right (Between 1-100) V-Position moves menu up and down (Between 1-100) OSD Setting Transparency to adjust transparency (between 0-100%) OSD Time-Out to adjust time OSD appears on screen (1-100) OSD Color to scroll through three OSD color modes A collection of protocol which operates over the DDC channel to...

  • Page 9: Technical Specification

    Technical Specification LCD Panel 59.9cm (23.6”) TFT (with LED back light) Power VESA DPMS compatible Management Off Mode, < 0.5 W Displayable Full HD 1920 x 1080 max. Resolution Vertical Frequency 60Hz max. Pixel Dimension 0.2715(H) ×0.2715(V) mm LCD Display Color 16.7M colors Tilt -5°~20°...
  • Page 10 Care • Avoid exposing your monitor directly to sunlight or other heat source. Place your monitor away from the sun to reduce glare. • Put your monitor in a well ventilated, clean, dry area. • Do not place any heavy things on top of your monitor. •...
  • Page 11 No Power • Make sure AC power cord is securely connected to the power adapter and the power supply is firmly connected to the monitor. • Plug another electrical device into the power outlet to verify that the outlet is supplying proper voltage. •...

  • Page 12: Safety Precautions

    Safety Precautions This monitor is manufactured and tested on a ground principle that a user’s safety comes first. However, improper use or installation may result danger to the monitor as well as to the user. Carefully go over the following WARNINGS before installation and keep this guide handy. WARNINGS •...
