- Page 1 CR Series User’s Manual CR-21 Remote Control For SR-1600 / SRC-2500...
- Page 2 1. Introduction 1-1. System The remote is designed to easily and quickly connect Cotek SR-1600 / SRC-2500. The LCD display is used for setting up the inverter/charger, as well as displaying current status or fault messages. Pressing buttons allows you to select a menu item or to save a setting, once it is displayed on the LCD screen.
- Page 3 1-2. Mechanical Drawings Unit: mm 1-3. Hardware Installation...
- Page 4 2. Display tree Power Switch ON INVERTER Initialization.. GRID-->SR-->LOAD OUTPUT：xxx.xV GRID：xxx.xV BATTERY：xxx.xV STATUS： BAT-------^ Major xx.xHz xxx.xA xx.xHz xxx.xA discharging xxx.xA Enter into System Setup by “press for 3 seconds” User Interface Bat Parameter AC Parameter LCD Contrast OVP Setting O/P Voltage 2-3-1 2-4-1...
- Page 5 2-1 GRID-->SR-->LOAD BAT-------^ Major The connection status and Alarm type. For the description of alarm type, (Major / Minor Alarm) please refer to Alarm List in the “SR-1600 User Manual.” 2-2 STATUS： It indicates Alarm Message. Please refer to LED Indicator in the SR-1600 User Manual.”...
- Page 6 2-4 Bat Parameter 2-4-1 OVP Setting : Set the Over Voltage Protection (OVP) and shutdown. Default = 34 VDC @ 24V Model. 68 VDC @ 48V Model Model Setting value range 30 VDC ~ 34 VDC 60 VDC ~ 68 VDC 2-4-2 OVP Recovery : When the DC input voltage is higher than the OVP setting, the SR series shuts down;...
- Page 7 Model Setting value range 19 VDC ~ 26 VDC 38 VDC ~ 52 VDC 2-4-6 Charging voltage : Default =54 VDC (For SRC) Model Setting value range 52 VDC ~ 58 VDC 2-4-7 Charging current : Default =0 A (For SRC) Model Setting value range 0A ~ 25A...
- Page 8 AC load 60%, DC load 40% AC load 70%, DC load 30% AC load 80%, DC load 20% AC load 90%, DC load 10% Disable No.33, Sec. 2, Renhe Rd., DaxiDist., Taoyuan City 33548, Taiwan Phone：+886-3-3891999 FAX：+886-3-3802333 http：// www.cotek.com.tw 2018.07._A1...
