OPTIONS
1. Discharge Delay Selection Switch S101
5
Switch
S101
Dial
Setting
0
1
2
3
4
5
6
7
8
9
2. Abort Station Operation Selection Dipswitch PS1
Position I Closed; II and Ill Open
Position II Closed; I and Ill Open
Position III Closed; I and II Open
ABORT
3. Manual Discharge Operation Selection Dipswitch PS2
Position I Closed; II Open
MANUAL DISCHARGE
MANUAL DISCHARGE
Dial setting
Rotate to change setting
Discharge Delay
Period (seconds)
0
5
10
15
20
25
30
35
40
45
ABORT
ABORT
Position II Closed; I Open
MANUAL DISCHARGE
NOTE:
4. Predischarge/Discharge Delay Operation Selection
(TB3, Terminals 10 through 14) Dipswitch PS3
Position I Closed; II Open
MANUAL DISCHARGE
Position II Closed; I Open
5. New York Option
If the ABORT switch is not pressed
If the ABORT switch is depressed before the 30
second time-in period ends.
NOTE:
MANIFOLD DISCHARGE
6.
