Back Panel - JBL CONTROL XSTREAM Quick Start Manual

JBL
®
Quick Start Guide
Guide de démarrage rapide
3

Back panel

1
2
3
4
*Wall bracket is not included.
Each JBL Control Xstream speaker contains a 3/8"-16 threaded insert on the back to facilitate the use
of third-party wall brackets.
Primary speaker
1. Wi-Fi status
2. Reset
3. AUX-in
4. Power input AC
5. Left / Right switch
6. Wall/Other equalization
(based on your installation)
7. Pairing
8
8. Threaded insert*
5
6
7
Secondary speaker
9. Wall/Other equalization
(based on your installation)
10. Pairing
11. Power input AC
12. Threaded insert*
12
9
10
11
