JBL V R X 9 1 5 M Brochure & Specs

STANDARD MODELS DESCRIPTION
System type:
Frequency Range (-10 dB):
Frequency Response (±3 dB):
Coverage pattern:
Power 1 (Continuous/Program/Peak):
Maximum System SPL
Components:
Dimensions (H x W x D):
Weight:
System type:
Frequency Range (-10 dB):
Frequency Response (±3 dB):
Coverage pattern:
1
Power (Continuous/Program/Peak):
Maximum System SPL
Components:
Dimensions (H x W x D):
Weight:
System type:
Frequency Range (-10 dB):
Frequency Response (±3 dB):
1
Power (Continuous/Program/Peak):
Maximum System SPL
Components:
Dimensions (H x W x D):
Weight:
System type:
Frequency Range (-10 dB):
Frequency Response (±3 dB):
1
Power (Continuous/Program/Peak):
Maximum System SPL
Components:
Dimensions (H x W x D):
Weight:
System type:
Frequency Range (-10 dB):
Frequency Response (±3 dB):
Coverage pattern:
1
Power (Continuous/Program/Peak):
Maximum System SPL
Components:
Dimensions (H x W x D):
Weight:
1 IEC filtered noise with 6 dB crest factor, 2 hours.
2 Calculated, based on power rating and sensitivity.
3 Calculated, based on sensitivity on horn with Q of 6.3, averaged in the 2 KHz octave band.
8500 Balboa Boulevard
Northridge, CA 91329 USA
Visit us online at www.jblpro.com
© 2007 JBL Professional
CAT VRX900 1/07
SPECIFICATION
8 inch, two way, line-array speaker
70 Hz - 20 kHz
87 Hz - 19 kHz
100° x 15° nominal (horizontal x vertical)
Passive: 400 W / 800 W / 1600W
Bi-amp LF: 400 W / 800 W / 1600W
Bi-amp HF: 30 W / 60 W / 120 W
2
: Passive: 122 dB;
Bi-amp LF: 122 dB; Bi-amp HF: 128 dB
LF: 2168H-1; HF: 2x 2414H (1.0 in voice coil)
230 mm x 420 mm x 270 mm
9.0 in x 16.5 in x 10.5 in
12.7 kg (28 lb)
12 inch, two way, line-array speaker
57 Hz - 20 kHz
75 Hz - 20 kHz
100° x 15° nominal (horizontal x vertical)
Passive: 800 W / 1600 W / 3200 W
Bi-amp LF: 800 W / 1600 W / 3200 W
Bi-amp HF: 75 W / 150 W / 300 W
2
: Passive: 130 dB;
Bi-amp LF: 130 dB; Bi-amp HF: 139 dB
LF: 2262H; HF: 3x 2407J (1.5 in voice coil)
349 mm x 597 mm x 381 mm
13.75 in x 23.5 in x 15.0 in
21.8 kg (48 lb)
15 inch, bass-reflex subwoofer
35 Hz - 250 Hz
40 Hz - 250 Hz
800 W / 1600 W / 3200 W
2
: 126 dB
LF: 2265G-1
496 mm x 420 mm x 597 mm
19.5in x 16.5 in x 23.5 in
26.3 kg (58 lb)
18 inch, bass-reflex subwoofer
31 Hz - 220 Hz
34 Hz - 220 Hz
800 W / 1600 W / 3200 W
2
: 130 dB
LF: 2268H
508 mm x 597 mm x 749 mm
20.0 in x 23.5 in x 29.5 in
37 kg (81 lb)
15 inch, two way, stage monitor
60 Hz - 20 kHz
70 Hz - 20 kHz
50° x 90° nominal (horizontal x vertical)
Passive: 800 W / 1600 W / 3200W
Bi-amp LF: 800 W / 1600 W / 3200W
Bi-amp HF: 75 W / 150 W / 300 W
2
: Passive: 133 dB;
3
Bi-amp LF: 131 dB; Bi-amp HF : 136 dB
LF: 2165H; HF: 2452H (4.0 in voice coil)
432 mm x 629 mm x 324 mm
(375 mm stage height)
17 in x 24.75 in x 12.75 in
(14.75 in stage height)
21 kg (46 lb)
© 2006 JBL Professional
CAT VRX900 9/06
C O N S T A N T C U R V A T U R E
V R X 9 3 2 L A
V R X 9 2 8 L A
V R X 9 1 8 S
V R X 9 1 5 S
V R X 9 1 5 M
L I N E A R R A Y
