- Page 1 Use, Care, and Installation Guide Guide d’utilisation, d’entretien et d’installation Guía de instalación, uso y mantenimiento READ AND SAVE THESE INSTRUCTIONS LISEZ CES INSTRUCTIONS ET CONSERVEZ-LES LEA Y CONSERVE Models: EST630SS ESTAS INSTRUCCIONES EST636SS LIB0132564 Printed in Mexico...
-
Page 2: Table Of Contents
ENGLISH Contents Important safety notice......................................... 3 Electrical & installation requirements ................................4 Before installing the hood ...................................... 4 Dimensions and clearances......................................4 List of materials..........................................5 Parts supplied ..........................................5 Parts not supplied ........................................5 Ducting options and examples....................................6 Installation ............................................ -
Page 3: Important Safety Notice
IMPORTANT SAFETY NOTICE I CAUTION I WARNING FOR GENERAL VENTILATING USE ONLY. DO NOT USE TO TO REDUCE THE RISK OF A RANGE TOP GREASE FIRE. EXHAUST HAZARDOUS OR EXPLOSIVE MATERIALS OR a) Never leave surface units unattended at high settings. VAPOURS. -
Page 4: Electrical & Installation Requirements
ELECTRICAL & INSTALLATION REQUIREMENTS IMPORTANT Copies of the standards listed may be obtained from: * National Fire Protection Association Batterymarch Park Quincy, Observe all governing codes and ordinances. Massachusetts 02269 ** CSA International 8501 East Pleasant Valley Road Cleveland, Ohio 44131-5575 It is the customer’s responsibility: • To contact a qualified electrical installer. -
Page 5: List Of Materials
LIST OF MATERIALS Removing the packaging. I CAUTION Remove carton carefully, Wear gloves to protect against sharp edges. I WARNING Remove the protective film covering the product before putting into operation. Supplied Part Pieces Supplied Part Pieces Upper: 1 Lower: 1 Lower and upper duct covers Hood assembly and LED lamps already installed... -
Page 6: Ducting Options And Examples
Ducting options Closely follow the instructions set out in this manual. All responsability, for any eventual inconveniences, damages or fires caused by not complying with the instructions in this manual, is declined. Ducting version Ductless (Recirculating) The hood is equipped with a 6” (15.2 cm) round transition In cases where it should not for discharge of fumes to the outside. - Page 7 4. Mark centers of the fastener locations through the Mark with a pencil the lower mounting holes location. template to the wall. Uninstall the hood assembly, and drill ⁄ ” (4.8 mm) pilot IMPORTANT: All screws must be installed into wood. holes at marked locations.
-
Page 8: Electrical Connection
Connect green (or bare) ground wire from home power Electrical Connection supply to yellow-green ground wire (F) in terminal box using UL listed wire connectors. Tighten strain relief screw. I WARNING Install terminal box cover. ELECTRICAL SHOCK HAZARD. 10 Check that all light bulbs are secure in their sockets. I WARNING 11 Reconnect power. -
Page 9: Complete The Installation
The hood will switch on at the most suitable speed based on the cooking fumes detected by the sensor on the hood. Automatic operation of the hood with the Elica Cooktop Operation of the hood will also depend on use of the Elica cooktop. Press the button . - Page 10 NOTE: Automatic operation with the cooktop is possible only CFM Reduction System with specific cooking cooktops; for further details, please con- tact the authorised dealer or technical assistance centre. Before operating your hood: Setting of parameters for Automatic Operation Some States and Provinces of the US & Canada restrict the NOTE: All calibration, selection, setting and logical connection maximum exhausting airflow of range hoods.
-
Page 11: Maintenance
Replacing a LED Lamp Maintenance The LED lights are replaceable by a service technician only. See “Who to contact” section in the warranty for service contact information. I ATTENTION! Before performing any maintenance operation, isolate the hood Charcoal Filter from the electrical supply by switching off at the connector and If the model is not vented to the outside, the air will be removing the connector fuse. -
Page 12: Warranty
PARTS AND SERVICE WARRANTY For the period of two (2) years from the date of the original purchase, Elica will provide free of charge, non consumable parts or components that failed due to manufacturing defects. During these two (2) years limited warranty, Elica will also provide free of charge, all labor and in-home service to replace any defective parts.
