IDNAC SLC Operation Advantage
TrueAlert Addressable speaker and speaker
visible appliances on IDNAC SLCs provide visible
and audio notification using two separate two-wire
circuits that also confirms connection to the individual
notification appliance's electronic circuit. This operation
increases circuit supervision integrity by providing
supervision that extends beyond the appliance wiring
connections.
Reduced current usage on IDNAC SLCs
A constant 29 VDC source voltage is maintained, even
during battery standby. This allows appliances to operate
at higher voltage with lower current and ensuring a
consistent current draw and voltage drop margin under
both primary power and secondary battery standby.
Efficiencies include wiring distances up to 2 to 3 times
farther than with conventional notification, support for
more appliances per IDNAC SLC, use of smaller gauge
wiring, or combinations of these benefits.
Reducing Installation and Testing Time
With separate controls on the same two-wire SLC,
installation time and expense for both retrofit and new
construction can be significantly reduced. When Class B
wiring is used, wiring can be "T" tapped, allowing more
savings in distance, wire, conduit (size and utilization), and
overall installation efficiency. Use of the magnet test feature
improves installation efficiency. TrueAlert device reports
conveniently identify information about each connected
appliance.
Wall Mount Appliance Product Selection
Wall Mount S/O Appliances*
Model Dimensions
49SO-APPLW(-BA)
5 ½" H x 5" W x 1 ½" D
(139 mm x 128 mm x 38 mm)
49HF-APPLW(-BA)
Wall Mount S/V Appliances*
multi-color strobe lens)
Model Series Dimensions
49SV-APPLW(-BA)
7 ⅜" H x 5" W x 1 ¾" D
49HFV-APPLW(-BA) (187 mm x 128 mm x 43 mm)
*Note: Wall mount models require separately ordered back plate. See related datasheet for details.
Ceiling Mount Appliance Product Selection
Ceiling Mount S/O Appliances
Model Dimensions
49SO-APPLC(-BA) 7 ⅛" H x 7 ⅛" W x 1 ¼" D
( 180 mm x 180 mm x 32 mm)
49HF-APPLC(-BA)
Ceiling Mount S/V Appliances
Model Series Dimensions
49SV-APPLC(-BA)
49HFV-APPLC(-BA)
49SVH-APPLC(-BA)
8 ⅛" H x 7 ⅛" W x 3" D
49HFVH-APPLC(-BA)
(206 mm x 180 mm x 76 mm)
49HFVH-APLCA-BA
49HFVH-APLCB-BA
Note: Select appliance, cover and mounting back plate (where required) separately. (-BA) indicates model is available either with or
without the -BA suffix. Model numbers ending in -BA are assembled in the USA
(Refer to data sheet S49SOW-0001 for full product selection including covers and mounting plates)
Description
S/O appliance only
High fidelity S/O appliance only
(Refer to data sheet S49SVW-0001 for full product selection including covers, mounting plates, and
Description
S/V appliance only
High fidelity S/V appliance only
(Refer to data sheet S49SOC-0001 for full product selection and installation requirements)
Description
S/O appliance only
High fidelity S/O appliance only
(Refer to data sheet S49SVC-0001 for full product selection and installation requirements)
Description
S/V appliance only
High fidelity S/V appliance only
High candela S/V appliance only
Clear lens high fidelity high candela
S/V appliance only
Amber lens high fidelity high
candela S/V appliance only
Blue lens high fidelity high candela
S/V appliance only
TrueAlert Addressable Wiring Isolator
Isolator Model 4905-9929 is available for remote
mounting on TrueAlert addressable circuits to isolate short
circuited wiring from functioning wiring. Refer to data sheet
S4905-0001 for additional information.
TrueAlert ES Diagnostics
Test Features
Controllers can be selected to pulse each appliance's LED
when it receives a supervision poll. When the controller is
selected for diagnostic mode, the appliance magnet test
feature provides a response at the individual appliance being
tested.
Silent Appliance Magnet Test
The appliance LED pulses sequentially to conveniently
indicate the appliance's address when a magnet is applied.
Operational Appliance Testing
In this test mode, after the address is indicated by pulsing the
appliance LED, the strobe will briefly flash to indicate
proper operation.
TrueStart Instrument Two (TSIT)
The 2nd generation of the Simplex TrueStart Test
Instrument adds testing of IDNAC SLC wiring and
TrueAlert (and TrueAlert ES) appliances to its ability to test
IDCs, NACs, and IDNet communications before connection
to the control panel. Please contact your local Simplex
representative for additional information.
2
Data Sheet Reference
S49SOW-0001
Data Sheet Reference
S49SVW-0001
Data Sheet Reference
S49SOC-0001
Data Sheet Reference
S49SVC-0001
S49SWC-0001-1 11/2015
