Saber Compact ATD-80200 Owner's Manual page 2

ITEM# ORDERING PART# PART DESCRIPTION
1 PRT80200-01
2 PRT80200-02
3 PRT80200-03
4 PRT80200-04
5 PRT80200-05
6 PRT80200-06
7 PRT80200-07
8 PRT80200-08
9 PRT80200-09
10 PRT80200-10
11 PRT80200-11
12 PRT80200-12
13 PRT80200-13
14 PRT80200-14
RIVET
DC COVER
SCREW GB/T M3x8
BACK COVER
SCREW ST2.9x6
SCREW M3x8
BATTERY HOLDER
LI-ION BATTERY
PCBA w/USB
SCREW M3x6
CLASP
O-RING 24
LEFT COVER
SWITCH LABEL
ITEM# ORDERING PART# PART DESCRIPTION
15 PRT80200-15
16 PRT80200-16
17 PRT80200-17
18 PRT80200-18
19 PRT80200-19
20 PRT80200-20
21 PRT80200-21
22 PRT80200-22
23 PRT80200-23
24 PRT80200-24
25 PRT80200-25
26 PRT80200-26
27 PRT80304-27
28 PRT80304-22
* PRT80304-31
ATD-80200
FRONT COVER
LENS
O-RING 36
LED
ALUMINUM HOUSING
WATERPROOF SEAL
RIGHT COVER
BRACKET COVER
BRACKET COVER
MAGNET
MAGNET LABEL
LED WIRING
USB CORD
AC ADAPTER
DC ADAPTER (OPTIONAL)
