Nivobob
®
Table of contents
Safety notes / Technical support
------------------------------------------------------------------------------------------------------
Introduction
------------------------------------------------------------------------------------------------------
Dimensions
------------------------------------------------------------------------------------------------------
Technical data
------------------------------------------------------------------------------------------------------
Options / Accessories
------------------------------------------------------------------------------------------------------
Mounting
------------------------------------------------------------------------------------------------------
Electrical installation
------------------------------------------------------------------------------------------------------
Signal overview
------------------------------------------------------------------------------------------------------
Programming NB 3000 Nivobob
------------------------------------------------------------------------------------------------------
Programming NB 9000 Remote Box
------------------------------------------------------------------------------------------------------
Commissioning
------------------------------------------------------------------------------------------------------
Diagnostics
------------------------------------------------------------------------------------------------------
Notes for use in Hazardous Locations
Subject to technical change.
All dimensions in mm (inches).
All units in this information are CE-certified.
NB 3000
Continuous level measuring system
NB 3000
Technical information / Instruction manual
Electrical Data
Mechanical Data
Operating conditions
Approvals
Sensor weight guide
NB 3000 Nivobob
NB 9000 Remote Box
Quickset menu
Output adjustment menu
Diagnostics menu
Communication menu
Modbus register
Interface measurement
Maintenance
Failure
We assume no liability for typing errors.
Different variations to those specified are possible.
Please contact our technical consultants.
gi130109
Page
G2
G3
G4
G8
G9
G10
G10
G11
G12
G14
G16
G20
G22
G24
G26
G29
G31
G32
G34
G36
G37
G39
G40
page G
1
2
3
4
5
6
7
8
9
10
11
12
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for UWT Nivobob NB 3000
Summary of Contents for UWT Nivobob NB 3000
- Page 1 Nivobob Continuous level measuring system ® NB 3000 Technical information / Instruction manual Table of contents Page Safety notes / Technical support ------------------------------------------------------------------------------------------------------ Introduction ------------------------------------------------------------------------------------------------------ Dimensions ------------------------------------------------------------------------------------------------------ Technical data Electrical Data Mechanical Data Operating conditions Approvals Sensor weight guide ------------------------------------------------------------------------------------------------------ Options / Accessories ------------------------------------------------------------------------------------------------------ Mounting...
-
Page 2: Safety Symbols
CAUTION: refer to related documents (manual) for details. Earth (ground) Terminal Protective Conductor Terminal Technical support Please contact your local supplier (see www.uwt.de for address). Otherwise you can contact: UWT GmbH Tel. 0049 (0)831 57123-0 Westendstr. 5 Fax. 0049 (0)831 76879 87488 Betzigau info@uwt.de... - Page 3 Nivobob Continuous level measuring system ® NB 3000 Technical information / Instruction manual Introduction Function The Nivobob NB 3000 is an electromechanic level measuring ® instrument for continuous measuring of level or volumes in silos, hoppers or tanks. The Nivobob NB 3000 is mounted on the top of the silo.
- Page 4 Nivobob Continuous level measuring system ® NB 3000 Technical information / Instruction manual Dimensions Basic type Flange version Thread version Housing Housing Housing extension Housing extension Flange Thread Socket Socket pipe pipe Rope / tape Rope / tape Flange version, bottom view Dimensions Flanges...
-
Page 5: Options And Accessories
Nivobob Continuous level measuring system ® NB 3000 Technical information / Instruction manual Dimensions Options and Accessories Pos. 25 Pos. 28 Window in lid and Compressed air outside start button connector Window in lid Compressed air connector Outside start button Sensor weights Solids measurement: Rope version All weights ca. - Page 6 Nivobob Continuous level measuring system ® NB 3000 Technical information / Instruction manual Dimensions Solids measurement: Tape version All weights ca. 2.1kg (4.6lbs) Stainless Folding Claw PVC with pin steel cover Aluminium 1.4305 (304) 380x380mm (15x15") X = 430mm (16.9") Material: 1.4310 (301) Ø95 (3.7") PA canvas...
- Page 7 Nivobob Continuous level measuring system ® NB 3000 Technical information / Instruction manual Dimensions NB 9000 Remote Box NB 9000 Panel mounting Terminal plug AC/DC converter Biasing network Mounting: DIN rail 35 Mounting: DIN rail 35 NB 9000 Wall mounting Mounting holes Depth 90mm (35.4") NB 3000...
-
Page 8: Technical Data
Nivobob Continuous level measuring system ® NB 3000 Technical information / Instruction manual Technical data Electrical data Power supply AC version 98 .. 253V 50-60Hz DC version 20 .. 28V (voltages incl. 10% of EN 61010) Installed load AC version: 150 VA (including internal heater (80W)) DC version: One unit:... -
Page 9: Mechanical Data
Nivobob Continuous level measuring system ® NB 3000 Technical information / Instruction manual Technical data Memory Non-volatile (no backup battery required) > 10 years data retention Connection terminals 0.14 .. 2.5mm (AWG 26 .. 14) Cable entry According to selection: Screwed cable gland: 2x M20x1.5 and 1x M25x1.5 Blindplug: 2x M20x1.5 Conduit ANSI B1.20.1: 1x NPT 3/4"+ 2x NPT 1/2"... - Page 10 Nivobob Continuous level measuring system ® NB 3000 Technical information / Instruction manual Technical data Operating conditions Process overpressure -0.3 ..+0.3bar (-4.4 ..+4.4psi) -0.5 .. + 1.7 bar (-7.3 .. +25psi) optional Process temperature -40°C ..+80 /150 / 250°C (-40 ..+176 / 302 / 482°F) Ambient temperature -20°C ..
- Page 11 Nivobob Continuous level measuring system ® NB 3000 Technical information / Instruction manual Technical data Sensor weight guide (solids measurement) Sensor weight Application Note Fits through mounting hole * Material Material Angle of Max. Thread Flange densitiy consistence repose process 3"...
- Page 12 Nivobob Continuous level measuring system ® NB 3000 Technical information / Instruction manual Options / Accessories Options Window in lid and Drawing see page G5 Enables to see the display through the closed lid and to external start button start a measurement without opening the lid. Material of the window: break-proof glass.
- Page 13 Nivobob Continuous level measuring system ® NB 3000 Technical information / Instruction manual Accessories Extension cables • For connecting the Remote Box NB 9000 • For wiring a Modbus network • Notes for choosing the right cable see chapter "Electrical Installation" •...
- Page 14 Nivobob Continuous level measuring system ® NB 3000 Technical information / Instruction manual Mounting General Safety Instructions Process pressure Improper installation may result in loss of process pressure. Chemical resistance Materials of construction are chosen based on their chemical compatibility (or inertness) for general purposes. against the medium For exposure to specific environments, check with chemical compatibility charts before installing.
- Page 15 Nivobob Continuous level measuring system ® NB 3000 Technical information / Instruction manual Mounting Measurement during filling Filling of the silo while measuring might cover the sensor weight with bulk material. Measurements during filling of the silo are possible, if there is enough distance to the infeed, so that no material can fall on the sensor weight. Sensor weight •...
-
Page 16: Electrical Installation
Nivobob Continuous level measuring system ® NB 3000 Technical information / Instruction manual Electrical installation General Safety Instructions Handling In case of improper handling or handling malpractice, the electric safety of the device cannot be guaranteed. Installation regulations The local regulations or VDE 0100 (Regulations of German Electrotechnical Engineers) must be observed. Fuse Use a fuse as stated in the connection diagrams. - Page 17 Nivobob Continuous level measuring system ® NB 3000 Technical information / Instruction manual Electrical installation Terminal location Display 0/4-20mA Start input Full detector input Modbus RTU Profibus DP Relais El. counting pulse Protective Power conductor supply terminal NB 3000 - Power supply and Signal input /output Power supply DC version AC version...
- Page 18 Nivobob Continuous level measuring system ® NB 3000 Technical information / Instruction manual Electrical installation Signal input: 0.14 .. 2.5mm Full detector (AWG 26 .. 14) Signal description: See page G22 Signal output: 0/4-20mA active, isolated 0.14 .. 2.5mm (AWG 26 .. 14) Signal description: See page G22...
- Page 19 Nivobob Continuous level measuring system ® NB 3000 Technical information / Instruction manual Electrical installation NB 3000 - Modbus network Setting Biasing and Termination Resistor For use of NB 3000 units in a external Modbus network, it is possible to set Biasing and Termination Resistor on each unit as required.
- Page 20 Nivobob Continuous level measuring system ® NB 3000 Technical information / Instruction manual Electrical installation Remote Box NB 9000 - Internal wiring and power supply Panel mounting NB 9000 panel version Note: NB 9000 COM1: Modbus D1 = Pin 1 and 4. Modbus D0 = Pin 8 and 9.
- Page 21 Nivobob Continuous level measuring system ® NB 3000 Technical information / Instruction manual Electrical installation Remote Box NB 9000 - Connecting to NB 3000 NB 9000 NB 3000 NB 3000 NB 3000 Unit 1 Unit 2 Unit x (see page before) Biasing network Last unit: Termination...
- Page 22 Nivobob Continuous level measuring system ® NB 3000 Technical information / Instruction manual Signal overview Signal input / output Signal input: • Floating contact (terminal 24, 25) or Start of measurement • 24 V DC voltage (terminal 25, 27), current consumption approx. 25mA, observe the polarity. Duration of starting signal: 0.7 to 5s The contact must be closed or the 24V signal must be present to start.
- Page 23 Nivobob Continuous level measuring system ® NB 3000 Technical information / Instruction manual Signal overview Relay 4 - set to "Upper stop postition" The signal allows the user to determine whether the measurement has come to its end. In this case the sensor weight is in its upper stop position, relay contacts are closed.
- Page 24 Nivobob Continuous level measuring system ® NB 3000 Technical information / Instruction manual Programming NB 3000 Nivobob Quickset menu The Quickset menu is used for fast and easy start-up of the system. If the unit is working in normal operation (measurement mode), the SETUP button brings up the Quickset menu. *Deutsch English Measurement mode...
-
Page 25: Factory Settings
Nivobob Continuous level measuring system ® NB 3000 Technical information / Instruction manual Programming NB 3000 Nivobob Programming buttons Continues with next adjustment item Continues with measurement display after parameter adjustment Starts measurement Cancels a Failure or Maintenance message Increases the value to be adjusted Decreases the value to be adjusted Runtime messages During measurement mode, following runtime indications are given:... - Page 26 Nivobob Continuous level measuring system ® NB 3000 Technical information / Instruction manual Programming NB 3000 Nivobob Output Adjustment menu The Output Adjustment menu is used for setting the 0/4-20mA, relais and internal timer *4-20mA Current output 0-20mA mode 20-4mA 20-0mA *0mA *Failure...
- Page 27 Nivobob Continuous level measuring system ® NB 3000 Technical information / Instruction manual Programming NB 3000 Nivobob Current output mode 100% Current output at level Setting 100% 4-20 mA 4 mA 20 mA 0-20 mA 0 mA 20 mA 20-4 mA 20 mA 4 mA 20-0 mA...
- Page 28 Nivobob Continuous level measuring system ® NB 3000 Technical information / Instruction manual Programming NB 3000 Nivobob Relay 3 Selects, if relay 3 shall indicate Failure, Maintenance or both situations. Failure / Maintenance Mode Mode Present present Relay 4 Selects, if relay 4 shall indicate "Upper stop position" or Maintenance. Upper stop position / Mode Mode...
-
Page 29: Diagnostics Menu
Nivobob Continuous level measuring system ® NB 3000 Technical information / Instruction manual Programming NB 3000 Nivobob Diagnostics menu The Diagnostics menu is used to diagnose the unit status and for manual motor driving mode Firmware version Sensor weight moves up or Manual motor control down while pressing... - Page 30 Nivobob Continuous level measuring system ® NB 3000 Technical information / Instruction manual Programming NB 3000 Nivobob Firmware version States the firmware version of the unit. Manual motor control The motor moves the sensor weight upwards while the "ARROW UP" button is beeing pushed. The motor moves the sensor weight downwards while the "ARROW DOWN"...
- Page 31 Nivobob Continuous level measuring system ® NB 3000 Technical information / Instruction manual Programming NB 3000 Nivobob Communication menu The Communication menu is used for setting parameters of Modbus RTU and Profibus DP *Modbus RTU Protocol Profibus DP 1 .. 247 Address (*100) 1200...
- Page 32 Nivobob Continuous level measuring system ® NB 3000 Technical information / Instruction manual Programming NB 3000 Nivobob Modbus Register The following registers describe the communication via Modbus. CAUTION Writing to the registers different from what is stated will cause a miss function of the unit Register Register Register...
- Page 33 Nivobob Continuous level measuring system ® NB 3000 Technical information / Instruction manual Programming NB 3000 Nivobob Explanation: Blocked: No measurement can be started. Ready: A new measurement can be started. Measurement valid: Indicates a valid measurement. Measurement not valid: Indicates a maintenance condition (details see M_MAINTENANCE) Busy: A measurement is actually running.
- Page 34 Programming • The programming can be done either directly on the Nivobob NB 3000 unit or via the Remote Box NB 9000. If programming is done on the Nivobob NB 3000 unit, no more programming of the Remote Box NB 9000 is required.
- Page 35 Nivobob Continuous level measuring system ® NB 3000 Technical information / Instruction manual Programming NB 9000 Remote Box Quickset page • Programming of: Max. move distance M 24.5m Max. mov. dist. M Silo Height H Air Distance A Silo height H 26.0m Cone height See page G24 for details.
- Page 36 Nivobob Continuous level measuring system ® NB 3000 Technical information / Instruction manual Commissioning: Interface measurement General items Applications Measurement of solids in water like mud, sand, bed ash, sediment, stones etc. Rope version: The material surface can be soft / muddy or compact. Sensitivity adjustment possible. Tape version: The material surface must be compact (the sensor weight cannot sink in).
- Page 37 Nivobob Continuous level measuring system ® NB 3000 Technical information / Instruction manual Diagnostics: Maintenance Result is an indication for the user with still valid measurement. Red LED is blinking. Relay 4 indicates Maintenance (programmable). The signal enables a preventive maintenance. Evaluating the signal can help to avoid losing the sensor weight inside the silo. If Maintenance was indicated, the measurement process can be continued.
- Page 38 Nivobob Continuous level measuring system ® NB 3000 Technical information / Instruction manual Diagnostics: Maintenance Rope/Tape lifetime The expected life time (measurement cycles) for the rope/tape is: Rope version: approx. 100000 Tape version: approx. 250000 Note: These values refer to lifetime tests under the following conditions: No excessive material influence.
- Page 39 Nivobob Continuous level measuring system ® NB 3000 Technical information / Instruction manual Diagnostics: Failure Result is an invalid measurement. Red LED is on. Relay 3 indicates Failure. The signal indicates critical situations. Evaluating the signal can help to avoid losing the sensor weight inside the silo. If Failure is indicated, the unit must be checked on site.
-
Page 40: General Notes
Nivobob Continuous level measuring system ® NB 3000 Technical information / Instruction manual Notes for use in Hazardous Locations ATEX Zone classification Category useable in zone 20, 21, 22 * in case of conductive dust, 21, 22 additional requirements for 3 D* installation are necessary. - Page 41 Nivobob Continuous level measuring system ® NB 3000 Technical information / Instruction manual Notes for use in Hazardous Locations Maximum Surface Temperature The temperature marking on the name plate refers to the instruction manual. On the following table the relevant temperature ratings are shown. The maximum surface temperature and the temperature class refer to the warmest area outside on the unit which can occur in failure case (according to EX definition).
