Quick start
Functions using the laser keypad
On/Off
Rotation speed
Stop rotation
Chalk line
Move stationary point
or chalk line left

Move stationary point

or chalk line right
Scanning
Increase scan angle
Decrease scan angle
Move left
scan or vertical alignment
Move right

scan or vertical alignment

H.I. Alert
Motorized mount mode
Raise laser on mount
Lower laser on mount
Manual mode
(slope on X axis)
* Functions not available in wall mount mode; exit to use these functions.
2
Press
Increase with ; decrease with
Press and hold until it stops
Flip collar on head up for chalk line,
down for point
Press
Press
Press simultaneously on and
Press (in scan mode)
Press (in scan mode)
Press *
Press *
Press H.I.
Press simultaneously on and
(scan keys) for several seconds; all 3
LEDS will blink and 4 beeps will sound
Press (in wall mount mode) on remote
Press (in wall mount mode) on remote
Press Man
(bottom LED will blink)

Table of contents

1. General information
1.1. Description
1.2. Safety
1.3. Specifications
1.4. Laser overview
1.5. Keypad overview
2. How to use the laser
2.1 Setup
2.2 Automatic/Manual
2.3 HI Alert

2.4 Rotation speed

2.5 Laser chalk line
2.6 Scanning
2.7 Motorized mount
2.8 Squaring
2.9 Matching slope
3. Power
3.1 Installing alkaline batteries
3.2 Using rechargeable batteries
3.2 Later recharging
4. Checking and adjusting calibration
5. Care and handling
6. Accessories
6.1 RCR500 detector
6.2 Remote control
6.3 Tripods
6.4 Other accessories
7. Warranty
