TECHPURE 24V GERMICIDAL UV SYSTEM INSTALLATION & OPERATION MANUAL
UV INSTALLATION NOTES
This device is meant only to be installed in
the duct portion of the HVAC system.
If the UV device is installed on the inlet side
(return air side) of a coil, make sure that the
HVAC system is configured such that the
blower is located between the return air filter
and the in-let of the coil, such as would be
found in a traditional up-flow, or horizontal
furnace with the coil placed after the heat
exchanger.
If the UV device is installed near an air filter,
check with filter manufacturer for UV-C
resistance properties. Optional lamp shield
accessory is available to protect air filter. Ask
your local wholesaler.
If the desired UV installation location is
intended to irradiate an air filter, to neutralize
the microbiological matter on the air filter
surface, such as would be found in the
return air drop of a basement application or
in the return plenum of a horizontal system
in an attic; take precautions as described in
note above, and make sure the UV fixture
is placed on the return side of the filter. DO
NOT INSTALL THE UV FIXTURE ON EITHER
SIDE OF THE FILTER IN HALL / CLOSET
RETURN AIR APPLICATIONS.
WARNING
UV Light Hazard.
Can cause serious eye and skin damage.
Do not look at UV-C light. Wear UV-C eye and skin protection.
Fig. 1 HVAC system.
