- Page 1 PCAN-MiniDiag FD PCAN-MiniDiag FD Diagnostic Device for CAN FD Buses User Manual Document version 1.0.0 (2019-01-24)
- Page 2 Part number PCAN-MiniDiag FD IPEH-003070 PCAN® is a registered trademark of PEAK-System Technik GmbH. CANopen® and CiA® are registered community trademarks of CAN in Automation e.V. All other product names mentioned in this document may be the trademarks or registered trademarks of their respective companies. They are not explicitly marked by “™”...
-
Page 3: Table Of Contents
PCAN-MiniDiag FD – User Manual Contents Introduction Properties at a Glance System Requirements Scope of Supply Putting the Device into Operation Inserting Batteries/Accus Turning on/off User Interface Operation Connecting to the CAN Bus Device Functions System Info 3.1.1 Available Options 3.1.2... - Page 4 PCAN-MiniDiag FD – User Manual 3.7.1 Initialized CAN Controller 3.7.2 Non-Initialized CAN Controller 3.7.3 Available Options Statistics Technical Specifications Appendix A CE Certificate Appendix B Dimension Drawing Appendix C Disposal Info (Batteries) Appendix D Signal Level of a High-speed CAN Bus...
-
Page 5: Introduction
PCAN-MiniDiag FD – User Manual Introduction The PCAN-MiniDiag FD is a compact, low-cost handheld device for basic diagnosis and checking of CAN and CAN FD buses. Service technicians and developers can easily access networks of vehicles, machines, or industrial equipment whose configuration is unknown. -
Page 6: System Requirements
PCAN-MiniDiag FD – User Manual CAN bit rates from 10 kbit/s up to 1 Mbit/s Microchip CAN transceiver MCP2558FD CAN bus connection via D-Sub, 9-pin (in accordance with CiA® 303-1) No influence to the CAN bus due to permanent listen-only mode... -
Page 7: Scope Of Supply
PCAN-MiniDiag FD – User Manual Scope of Supply PCAN-MiniDiag FD in plastic casing Batteries (4 x 1,5 V Micro AAA) Manual in PDF format Printed quick start guide... -
Page 8: Putting The Device Into Operation
For more information, see to the section 3.1.1 on page 13. Turning on/off The PCAN-MiniDiag FD is turned on and off by pressing the Enter . Press the Enter key once to turn on the device. -
Page 9: User Interface
PCAN-MiniDiag FD – User Manual Figure 1: Start screen after turning on To turn off the device again, press and hold the Enter key three seconds. User Interface The display consists of three fixed areas: status bar (top), main bar (middle), and info bar (bottom). -
Page 10: Operation
With the previous settings are not changed. Operation The PCAN-MiniDiag FD is operated via four keys. Navigation and selection are done using the arrow keys . The gear wheel key opens the options of the currently displayed function. -
Page 11: Connecting To The Can Bus
PCAN-MiniDiag FD – User Manual Connecting to the CAN Bus The PCAN-MiniDiag FD has a 9-pin D-Sub connector. The CAN assignment corresponds to the CiA® 303-1 specification. Figure 4: D-Sub connector of the PCAN-MiniDiag FD at the rear of the housing. -
Page 12: Device Functions
PCAN-MiniDiag FD – User Manual Device Functions This chapter deals with the device functions of the PCAN-MiniDiag FD. The following subchapters describe the eight functions. Navigation is carried out using the arrow keys . In the following table, all functions are listed in order to the right... -
Page 13: System Info
PCAN-MiniDiag FD – User Manual System Info With the function, information about the installed System Info Firmware, the version, the serial number (S/N) and the Hardware charge status of the batteries (Battery) is displayed. Further information and the status of the calibration can be reached by pressing the Enter key (Next). -
Page 14: Battery Voltage Display
PCAN-MiniDiag FD – User Manual update with the help of the PCAN-Flash software. The bootloader is loaded by selecting the option and confirming with the Enter . If no firmware update is performed within a period of 45 seconds, the device turns off. -
Page 15: D-Sub Voltages
PCAN-MiniDiag FD – User Manual D-Sub Voltages Attention! Do not apply voltages out of the measuring range from -40 to 43 volts in order to avoid damage to devices and persons. At the function, the external voltages at pins 6... -
Page 16: Can Min/Max
PCAN-MiniDiag FD – User Manual CAN Min/Max With the function, the minimum and maximum CAN Min/Max voltages at (pin 7) and (pin 2) are measured and CAN-H CAN-L stored. The values can be reset via the Enter key (Reset). The measuring range is within -5 to +8 volts. -
Page 17: Available Options
PCAN-MiniDiag FD – User Manual 3.4.1 Available Options The following option is available via the gear wheel key: Update time A time of seconds can be set in which the measurement should be repeated. The values can also be updated using the Enter (Update) with the setting manual. -
Page 18: Evaluation Of The Measurement
No or a too large termination resistor (> 1,2 k) is present on the CAN bus. Set up a correct termination. shorted Short circuit (< 10 )! Check whether the PCAN-MiniDiag FD has been properly connected and terminated. Jumping value Check whether the PCAN-MiniDiag FD has been connected correctly. -
Page 19: Bit Rate
PCAN-MiniDiag FD – User Manual Bit Rate With the function, the nominal bit rate, the data bit rate, Bit Rate and the related sample points are automatically determined by bit timing measurements. The automatic detection is started with the Enter key . -
Page 20: Available Options
The selected time is displayed in the function in the info bar under the Bit Rate abbreviation TO. 3.6.2 Status Messages The PCAN-MiniDiag FD outputs the following status messages during or after an unsuccessful measurement of the transmission rate:... -
Page 21: Manual Configuration
CAN traffic on the CAN bus. No CAN activity The device cannot detect any CAN traffic. Make sure detected. No bit that the PCAN-MiniDiag FD is properly connected and rate scan possible. the bus is terminated. Not enough CAN The device has received too few CAN frames. - Page 22 PCAN-MiniDiag FD – User Manual Enable CAN FD CAN FD is enabled with yes. This is followed by CAN FD options. is selected, the configuration is completed. CAN FD Options Enable Data BR A data bit rate for CAN FD frames is enabled with yes. In addition, the following options appear: SP.
-
Page 23: Bus Load
PCAN-MiniDiag FD – User Manual Bus Load With the function, the bus load on the CAN bus is Bus Load represented by percentage value(s) and a progression chart. The progress diagram is represented by a graph whose speed is influenced by the set measurement time (GT). -
Page 24: Non-Initialized Can Controller
PCAN-MiniDiag FD – User Manual 3.7.2 Non-Initialized CAN Controller If the CAN controller has not been initialized (Not initialized!), a value range for the bus load is displayed in the Bus Load function. Within this range lies the exact bus load value. This is made possible by measuring the duration of the dominant states on the CAN bus. -
Page 25: Statistics
PCAN-MiniDiag FD – User Manual Statistics function can only be completely displayed after Statistics the bit rate has been determined successfully. Then messages for CAN (MsgCnt) and CAN FD (MsgCntFD) as well as faulty CAN frames (ErrorCnt) on the bus are counted. Likewise, the current... -
Page 26: Technical Specifications
PCAN-MiniDiag FD – User Manual Technical Specifications Supply Current consumption max. 100 mA Voltage supply 3 x Micro AAA with 1.2 or 1.5 Volt, replaceable Operating time ~ 10 h D-Sub Connector Function CAN connector Number of pins 9-pole, assignment according to specification CiA®... - Page 27 PCAN-MiniDiag FD – User Manual Weight (with batteries) 164 g Weight (without batteries) 130 g Environment Operating temperature With supplied batteries: -10 - +50 °C (-14 - 122 °F) Without supplied batteries: -20 - +70 °C (-4 - 158 °F) Temperature for storage -30 - +80 °C (-22 - 176 °F) (without batteries)
-
Page 28: Appendix Ace Certificate
PCAN-MiniDiag FD – User Manual Appendix A CE Certificate... -
Page 29: Appendix B Dimension Drawing
PCAN-MiniDiag FD – User Manual Appendix B Dimension Drawing Figure 17: Dimension drawing of the PCAN-MiniDiag FD. The figure does not correspond to the actual size. -
Page 30: Appendix C Disposal Info (Batteries)
The device and the batteries it contains must not be disposed of with household waste. Remove the batteries from the unit for proper separate disposal. The PCAN-MiniDiag FD contains the following batteries: 3 batteries/rechargeable batteries, size AAA, 3 x 1.5 V or 3 x 1.2 V... -
Page 31: Appendix D Signal Level Of A High-Speed Can Bus
PCAN-MiniDiag FD – User Manual Appendix D Signal Level of a High-speed CAN Bus The PCAN-MiniDiag FD provides two device functions for checking the CAN lines CAN-High and CAN-Low. This appendix provides a brief explanation of the interpretation of the measurement results.
