SPECIFICATIONS

In no event shall LEIGHTRONIX be liable for any damages whatsoever resulting from loss of use, data, or profits, whether
or not advised of the possibility of damage, and on any theory of liability, arising out of or in connection with the use or
performance of the LABvault-HD.
Dimensions
Weight, without carton
or cables
Front Panel Display
Keypad
Power Input
Power Supply
Product Safety
Internal Real Time
Clock
Configuration Storage
Ethernet Network Host
Management
Firmware
Administrative Web
Interface
Internal Storage
Page 30
1.75"H x 14"W x 9"D (19"W with rack ears)
5 lbs.
2x16 character liquid crystal display
Six push button keypad
• Four arrow push buttons provide password-protected front panel status and
network configuration
• Green check button powers on the unit
• Red "X" button powers off the unit
Three-position IEC power input with removable power cord
Internal 200W power supply with active P.F.C., which accepts 90-264VAC @ 47-
63Hz
Certified and listed as:
• Audio, Video, and Similar Electronic Apparatus Safety Requirements ANSI/UL
60065, 7th edition
• Audio, Video, and Similar Electronic Apparatus Safety Requirements CAN/CSA
C22.2 No. 60065:03, 1st edition
Type: microprocessor interfaced
Reference: crystal controlled, temperature compensated
Accuracy: +/- 5 seconds per month
• Internal battery-backed memory
• Data integrity verified
• Elements:
IP address
►
Subnet mask
►
Gateway
►
User Information
►
• Remote Support: Dial-Up Networking
• Network Support Interface:
Eight-position, eight-conductor RJ-45 modular jack, 10/100/1000 BASE-T,
►
unshielded twisted pair, Ethernet
Ethernet_II frame type
►
Protocol: TCP/IP
►
Services: Telnet, FTP, Web
►
• Updateable via Ethernet
• Cyclical redundancy check (CRC) verified at time of reprogram
• Password-protected
• Provides setup for automatic file transfers to one of the following destinations:
LEIGHTRONIX E-HD2
►
Any destination with FTP capabilities
►
250 GB internal hard drive provides 200 GB of digital media storage
LABvault-HD
Specifications
