DECODER SPECIFICATIONS

In no event shall LEIGHTRONIX be liable for any damages whatsoever resulting from loss of use,
data, or profits, whether or not advised of the possibility of damage, and on any theory of liability, aris-
ing out of or in connection with the use or performance of the IncodeX One Point-to-Point HD decod-
er.
Dimensions
Weight, without carton
or cables
Front Panel Indicator
Power Input
Power Supply
Product Safety
Compliance
Operating Environment
Operating Temperature
Memory
Input
Outputs
Video Decoding
Audio
Page 18
1.46"H x 4.02"W x 3.8"D
.66 lbs.
One LED provides status on power and reception of IR commands
Three-position IEC power input with removable power cord
5V DC at 1.5A via external power supply, less than 8 W typical usage, accepts 100-
240VAC @ 50-60Hz 3A max
CAN/ CSA-C22.2 No. 60950-1-03 EN60950
FCC Part 15 class B. 2004/108/EC EN55022
ETS 300-019-1-3 Class 3.1
0°C (32°F) to 40°C (104°F)
128MB Flash, 256MB RAM
1 Ethernet 10/100 BASE-T via RJ-45 shielded connector
HDMI 1.3a. with HDCP and CEC. 10-way Mini-DIN for Composite video, Component
(YPrPb), RGB, S-Video and analog audio. S/PDIF (optical). 2x USB2.0. RS232 se-
rial connector
The IncodeX One Point-to-Point decoder supports the following:
• Codecs:
MPEG-2 MP@HL
►
MPEG-4 pt10 AVC/H.264 HP@L4
►
• Video Resolution: up to 1080i and 720p
Analog stereo audio out. Stereo via S-PDIF and HDMI. Dolby
