- Page 1 Sound Spot SFQ-07 User Manual...
- Page 2 Side View: CAUTION - Proper Installation Install the system in a place which is level, dry and neither too hot nor too cold. The appropriate temperature is between 5 oC Front side Back side and 35 oC. Install the system in a location with 15 cm adequate ventilation to prevent internal heat from building up inside the unit.
-
Page 3: Table Of Contents
Contents Getting Started ....................6 Package Contents ......................... 6 Charging the Built-in Battery ......................6 Checking Battery Capacity ......................7 System Overview ..................8 Front View ............................. 8 Rear View ............................9 Basic Operation ..................10 Turning on/off the System ......................10 Adjusting the Volume........................ -
Page 4: Getting Started
Getting Started Package Contents Examine whether the following package contents are all included: Main Unit USB Power Cable x 1 Aux Cable x 1 Charging the Built-in Battery This system has a built in Lithium Ion battery to give you portable power. To charge the system, connect the micro plug of the USB power cable to the 5V IN jack of the system and the standard plug to USB power output port such as PC USB port. -
Page 5: Checking Battery Capacity
During charging, the charging LED indicator combination with the button will indicate the charging status as follows: System Mode During Charging Charging Complete Standby Blinks in green light at a Blinks in white light at a slow slow rate. rate. Power On but in idle mode Blinks in green light. -
Page 6: System Overview
System Overview Front View 1. VOL - button Tap to decrease the volume level. 2. VOL + button Tap to increase the volume level. (Previous/Rewind) button In Bluetooth mode, tap to skip a previous track. Hold to rewind a track fast. (Play/Pause) button In Bluetooth mode, tap to play or pause a track. -
Page 7: Rear View
8. AUX IN jack Rear View Inputs audio signals from an external device. Establish dual system playback with another system (purchased separately) via AUX cable (Supplied). 9. AUX OUT jack Outputs audio signals to an external device. Establish dual system playback with another system (purchased separately) via AUX cable (Supplied). -
Page 8: Basic Operation
Basic Operation Turning on/off the System Press the button on the top to turn on the System. On/Standby button FLAT WARM BRIGHT Activating the Power Saving Mode Tap and hold PAIR button and the Press the button again to turn off the button together to disable the Power Saving System. -
Page 9: Selecting The Sound Source
Selecting the Sound Source This system enables you to access two sound sources – AUX IN and Bluetooth. If AUX IN jack has been inserted, the sound source will switch to AUX IN mode automatically. Remove the AUX cable from the AUX IN jack, the sound source will switch to Bluetooth mode automatically. -
Page 10: Playing Back Via Bluetooth
Playing back via Bluetooth After a Bluetooth connection is Establishing a Bluetooth established successfully, the LED Connection indicator will remain on in white light. Notes: Select the desired music and press Play Before establishing the Bluetooth button on your device. The system connection, make sure the AUX IN jack automatically starts playing back the is not inserted by AUX cable. -
Page 11: Playing Back From Macbook Or Macbook Pro
6. Double click the Sound Spot icon and Playing back from Macbook or the device connection screen will be Macbook Pro shown. 1. In the desktop screen, select the Open 7. Click the Connect button in the Music Bluetooth Preference. and Audio option. -
Page 12: Playing Back From External Source
Playing back from External Source You can enjoy the sound from an optional component such as a digital music player through the speakers of this system. Be sure to turn off the power of each component before making any connections. For details, refer to the instruction manual of the component to be connected. Connect an external device to the AUX IN jack on the back panel of the system using a stereo audio cable (supplied). -
Page 13: Outputting To Other Audio System
Outputting to other Audio System This system has AUX OUT jack allowing you to connect to auxiliary audio systems such as speaker, audio amplifier and perhaps wireless audio transmitter. Be sure to turn off the power of each component before making any connections. For details, refer to the instruction manual of the component to be connected. -
Page 14: Dual System Playback
Dual System Playback Two Sound Spot systems can be connected together via the supplied AUX cable, and they will play as one speaker system with left and right audio split between each for true stereo separation. For obtaining the stereo sound effect, you should purchase another Sound Spot system separately. -
Page 15: Charging An External Device
Charging an External Device The USB 5V jack can be used to charge most devices that allow for USB charging (including many mobile phones, smart phones and wireless headsets). 1. Connect one end of USB power cord to USB 5V jack of the system, and the other end to your USB device. -
Page 16: Troubleshooting
Troubleshooting Check this list for a possible troubleshooting solution before calling for service. In These Cases Check the Following Points Power does not come on. The built-in lithium battery is no power. Charge the battery. No sound output. Check if the volume level is set to the minimum. Check if the volume level of your Bluetooth device connected to the system is set to the minimum. -
Page 17: Technical Specifications
Technical Specifications Model SFQ-07 Type Sound Spot Support Bluetooth Bluetooth 1.2, 2.0 and 2.1 complaint Support Profile A2DP, AVRCP Input Sensitivity AUX Input 0.3-0.5V (1.2V max) Input Terminal External USB IN (for charging the battery), AUX IN Power Source DC 5V (External USB IN) Dimensions (Approx.) 133mm (L) x 60.5mm (D) x 128mm (H) Weight... - Page 18 Save this manual...
