LogicMark CaretakerSentry Quick Install Manual page 2

1
Confirm Accessories in Kit
4 Rechargable AA Telephone Cord
Batteries
Lanyard
2
Place Batteries in Unit.
OFF
ON
Place Green Rechargeable batteries in the
compartment on the bottom of the base
unit. Make sure to turn ON/OFF switch
to ON. You will hear the announcement
"Running on Battery Power." Unit will
do so until the AC Adapter pwer supply
is plugged in.
CaretakerSentry Step-by-Step Installation
AC Adapter
Wrist strap
Model #40911
To
Line
House
in Phone
Plug the AC Adapter
power cord into the power
jack and twist right to lock.
4
Test the Unit
Performing a System Test
a. PUSH and HOLD the CANCEL button for 8-10 seconds to enter "System Check"
b. Push GRAY EMERGENCY button for 2 seconds on Pendant
(RED LED on the pendant should turn ON for 1 second)
c. Listen for voice prompt from base unit:
i. "All Systems are OK – Battery is OK" is heard system is correctly installed
ii. If any other voice prompt is heard, the unit will describe the problem
d. Push and release the CANCEL button for 1 second to exit Test Mode
(unit will automatically exit in 3 minutes)
e. We recommend that you perform this System Test weekly
Place call to Emergency Operator:
a. Push GRAY EMERGENCY button for 2 seconds on Pendant (RED LED
on the pendant should turn ON for 1 second)
b. You should hear a dial tone, dialing and then communication tones
between the CaretakerSentry and central station. Several seconds later
the operator should answer the call and ask "Is everything OK"
c. Talk normally to the base unit – just like speaker phone
d. At the end of the conversation, the CaretakerAlert should automatically
hang-up – if not, push the CANCEL button for 1 second.
Plug Telephone Line and
3
Power Cord into Wall Jacks
(OPTIONAL) Plug
the telephone
into the "To House
Phone" jack.
