- Page 1 National Instruments USB-TC01 Manual Get Pricing & Availability at ApexWaves.com Call Today: 1-800-915-6216 Email: sales@apexwaves.com https://www.apexwaves.com/modular-systems/national-instruments/temperature-input-devices/USB-TC01...
-
Page 2: Safety Guidelines
The National Instruments USB-TC01 data acquisition (DAQ) device provides a Full-Speed USB interface for a single thermocouple channel. This user guide describes how to use the device. For specifications, refer to the NI USB-TC01 Device Specifications document available at ni.com/manuals. Figure 1. NI USB-TC01 Device... - Page 3 Working voltage is the highest rms value of an AC or DC voltage that can occur across any particular insulation. MAINS is defined as a hazardous live electrical supply system that powers equipment. Suitably rated measuring circuits may be connected to the MAINS for measuring purposes. 2 | ni.com | NI USB-TC01 User Guide...
-
Page 4: Installing The Ni Usb-Tc01
Thermocouple Input section for more information. Connect the NI USB-TC01 USB cable into an available USB port on the computer. On first connection to the computer, it may take a few seconds for the operating system to detect and configure the NI USB-TC01 device. -
Page 5: Led Indicator
Once the device has been detected, the NI USB-TC01 launch screen will open, as shown in Figure 3, or a Windows Autoplay dialog will appear allowing you to select TC01Launcher.exe to run the software. Note You must connect the NI USB-TC01 to the computer for the launch screen to open. -
Page 6: Taking Measurements With Software
NI USB-TC01 from the NI USB-TC01 launch screen. Creating Custom Software In addition to taking measurements with the NI USB-TC01 launch screen, you can also build custom software for your NI USB-TC01 with LabVIEW and NI-DAQmx driver software. LabVIEW uses graphical icons and wires that resemble a flowchart, so you can graphically wire together function blocks to create your own applications for logging data, alarming, triggering, reporting, and performing real-time data analysis. -
Page 7: Ni Usb-Tc01 Circuitry
Temperature measurement errors depend in part on the thermocouple type, the temperature being measured, the accuracy of the thermocouple, and the cold-junction temperature. Error graphs for each thermocouple type connected to the NI USB-TC01 are provided in the NI USB-TC01 Device Specifications document, available at ni.com/manuals. -
Page 8: Thermocouple Input
Thermocouple Input The NI USB-TC01 supports the J, K, R, S, T, N, E, and B thermocouple types. The thermocouple input supports the standard mini thermocouple connector. Figure 7. Mini Thermocouple Connector If your thermocouple has bare wire leads, you can purchase a screw terminal mini thermocouple connector to use with the NI USB-TC01. -
Page 9: Cold-Junction Temperature Measurement Accuracy
Figure 8. NI USB-TC01 Software Open Thermocouple Message Note During an open thermocouple condition, some invalid values may be returned before the open thermocouple is reported. Cold-Junction Temperature Measurement Accuracy Heat from other nearby heat sources can cause errors in thermocouple measurements by heating up the terminals so that they are at a different temperature than the cold-junction compensation (CJC) sensor used to measure the cold junction. -
Page 10: Where To Go From Here
The NI USB-TC01 online support page contains links to the most recent product documentation, drivers and updates, KnowledgeBase documents, tutorials, and example code. The NI USB-TC01 support page is accessible from the NI USB-TC01 launch screen by selecting the Device Support link or from by entering Info Code ni.com/info... - Page 11 Other product and company names mentioned herein are trademarks or trade names of their respective companies. For patents covering National Instruments products/technology, refer to the appropriate location: Help»Patents in your software, the file on your media, or the National Instruments Patent Notice at .
