Storage; Miscellaneous - Scale Computing HC3 Installation Manual

Storage
HC1200
4TB RAW Capacity / 2TB Usable Capacity (4x1TB)
3TB RAW Capacity / 1.5TB Usable Capacity (3x1TB)
HC1250
480GB RAW Capacity / 240GB Usable Capacity (1x480GB)
3TB RAW Capacity / 1.5TB Usable Capacity (3x1TB)
HC1250D
960GB RAW Capacity / 480GB Usable Capacity (1x960GB)
HC1250DF
3.84TB RAW Capacity / 1.92TB Usable Capacity (4x960GB)
Miscellaneous
HC1200
1.7" (43mm) H x 17.2" (437mm) W x 25.6" (650mm) D
HC1250
1.7" (43mm) H x 17.2" (437mm) W x 25.6" (650mm) D
HC1250D
1.7" (43mm) H x 17.1" (434mm) W x 28.1" (715mm) D
HC1250DF
1.7" (43mm) H x 17.1" (434mm) W x 28.1" (715mm) D
©
Scale Computing 2019 ​
Standard Storage
NL-SAS (7200 RPM)
NL-SAS (7200 RPM)
SSD
NL-SAS (7200 RPM)
SSD
SSD
Rack
1U Rack Height
1U Rack Height
1U Rack Height
1U Rack Height
Storage Upgrade Options
NL-SAS (7200 RPM)
8TB RAW Capacity / 4TB Usable Capacity (4x2TB)
16TB RAW Capacity / 8TB Usable Capacity (4x4TB)
32TB RAW Capacity / 16TB Usable Capacity (4x8TB)
NL-SAS (7200 RPM)
6TB RAW Capacity / 3TB Usable Capacity (3x2TB)
12TB RAW Capacity / 6TB Usable Capacity (3x4TB)
24TB RAW Capacity / 12TB Usable Capacity (3x8TB)
SSD
960GB RAW Capacity / 480GB Usable Capacity (1x960GB)
1.92TB RAW Capacity / 960GB Usable Capacity (1x1.92TB)
3.84TB RAW Capacity / 1.92TB Usable Capacity (1x3.84TB)
7.68TB RAW Capacity / 3.84TB Usable Capacity (1x7.68TB)
NL-SAS (7200 RPM)
6TB RAW Capacity / 3TB Usable Capacity (3x2TB)
12TB RAW Capacity / 6TB Usable Capacity (3x4TB)
24TB RAW Capacity / 12TB Usable Capacity (3x8TB)
SSD
1.92TB RAW Capacity / 960GB Usable Capacity (1x1.92TB)
3.84TB RAW Capacity / 1.92TB Usable Capacity (1x3.84TB)
7.68TB RAW Capacity / 3.84TB Usable Capacity (1x7.68TB)
SSD
7.68TB RAW Capacity / 3.84TB Usable Capacity (4x1.92TB)
15.37TB RAW Capacity / 7.68TB Usable Capacity (4x3.84TB)
30.72TB RAW Capacity / 15.36TB Usable Capacity
(4x7.68TB)
Certifications
UL/CB, CE, FCC
Miscellaneous
Rack Rails, Power Cables, Bezel
Onboarding Reference Card
Version 3.0: 02/2019 |
