EN 130 8. Q528.2E LB
8.4.4

Opt. No. (Option numbers)

Select this sub menu to set all options at once (expressed in
two long strings of numbers).
An option number (or "option byte") represents a number of
different options. When you change these numbers directly,
you can set all options very quickly. All options are controlled
via eight option numbers.
When the NVM is replaced, all options will require resetting. To
be certain that the factory settings are reproduced exactly, you
must set both option number lines. You can find the correct
option numbers on a sticker inside the TV set and in Table
"Option code overview". It should be noted that the option
codes are subject to modification and therefore, the options
given in the table are for indication only. In case of a mismatch
between the table and the sticker, the sticker is leading!
Example: The options sticker gives the following option
numbers:
• 04368 00005 01066 08707
• 00000 00032 00512 00000
8.4.5

Option Code Overview

Table 8-5 Option code overview
CTN_alt BOM#
32PFL7203D/10_1
32PFL7203D/10_2
32PFL7203H/10_1
32PFL7203H/10_2
32PFL7203D/12_1
32PFL7203D/12_2
32PFL7403D/10_1
32PFL7403D/10_2
32PFL7403D/12_1
32PFL7403D/12_2
32PFL7403H/10_1
32PFL7403H/10_2
32PFL7403S/60_1
32PFL7403S/60_2
32PFL7423H/10_1
32PFL7423H/10_2
32PFL7423D/12_1
32PFL7423D/12_2
32PFL7433D/12_1
32PFL7433D/12_2
32PFL7433S/60_1
32PFL7433S/60_2
32PFL7603D/10_1
32PFL7603D/10_2
32PFL7603D/12_1
32PFL7603D/12_2
32PFL7603H/10_1
32PFL7603H/10_2
32PFL7603S/60_1
32PFL7603S/60_2
32PFL7613D/12_1
32PFL7613D/12_2
37PFL7603D/10
37PFL7603H/10
37PFL7603S/60
42PFL5603D/10_1
42PFL5603D/10_2
42PFL5603D/12_1
42PFL5603D/12_2
42PFL5603H/10_1
42PFL5603H/10_2
42PFL7603D/10_1
42PFL7603D/10_2
42PFL7603D/12_1
42PFL7603D/12_2
42PFL7603S/60_1
42PFL7603S/60_2
Alignments
Options Group 1
41481 04109 04175 45160
41481 04109 04175 45160
41481 04109 04171 45160
41481 04109 04171 45160
41481 04109 04175 45160
41481 04109 04175 45160
41481 04109 04175 45160
41481 04109 04175 45160
41481 04109 04175 45160
41481 04109 04175 45160
41481 04109 04171 45160
41481 04109 04171 45160
41481 04109 04175 45160
41481 04109 04175 45160
41481 04109 04171 45160
41481 04109 04171 45160
41481 04109 04175 45160
41481 04109 04175 45160
41481 04109 04175 45160
41481 04109 04175 45160
41481 04109 04175 45160
41481 04109 04175 45160
41641 04109 04175 45160
41641 04109 04175 45160
41641 04109 04175 45160
41641 04109 04175 45160
41641 04109 04171 45160
41641 04109 04171 45160
41641 04109 04175 45160
41641 04109 04175 45160
41641 04109 04175 45160
41641 04109 04175 45160
41641 04109 04175 45160
41641 04109 04171 45160
41641 04109 04175 45160
41481 04107 04175 45160
41481 04107 04175 45160
41481 04107 04175 45160
41481 04107 04175 45160
41481 04107 04171 45160
41481 04107 04171 45160
41641 04108 04175 45160
41641 04108 04175 45160
41641 04108 04175 45160
41641 04108 04175 45160
41641 04108 04175 45160
41641 04108 04175 45160
The first line (group 1) indicates hardware options 1 to 4, the
second line (group 2) indicates software options 5 to 8.
Every 5-digit number represents 16 bits (so the maximum value
will be 65536 if all options are set).
When all the correct options are set, the sum of the decimal
values of each Option Byte (OB) will give the option number.
See tables "Option code overview" for the options.
Diversity
Not all sets with the same Commercial Type Number (CTN)
necessarily have the same option code!
Use of Alternative BOM
An alternative BOM number usually indicates the use of an
alternative display. This results in another display code thus in
another Option code. Refer to chapter 2 "Safety Instructions,
Warnings, and Notes".
Options Group 2
10053 00098 00000 00000
10120 00098 00000 00000
10053 00102 00000 00000
10120 00102 00000 00000
10053 00098 00000 00000
10120 00098 00000 00000
10118 00098 00000 00000
10138 00098 00000 00000
10118 00098 00000 00000
10138 00098 00000 00000
10118 00102 00000 00000
10138 00102 00000 00000
10118 00098 00000 00000
10138 00098 00000 00000
10118 00102 00000 00000
10138 00102 00000 00000
10118 00098 00000 00000
10138 00098 00000 00000
10118 00098 00000 00000
10138 00098 00000 00000
10118 00098 00000 00000
10138 00098 00000 00000
10053 00098 00001 00000
10120 00098 00001 00000
10053 00098 00001 00000
10120 00098 00001 00000
10053 00102 00001 00000
10120 00102 00001 00000
10053 00098 00001 00000
10120 00098 00001 00000
10053 00098 00001 00000
10120 00098 00001 00000
10113 00098 00001 00000
10113 00102 00001 00000
10113 00098 00001 00000
10115 00098 00004 00000
10114 00098 00004 00000
10115 00098 00004 00000
10114 00098 00004 00000
10115 00102 00004 00000
10114 00102 00004 00000
10115 00098 00001 00000
10114 00098 00001 00000
10115 00098 00001 00000
10114 00098 00001 00000
10115 00098 00001 00000
10114 00098 00001 00000
Displ. (code)
069
136
069
136
069
136
134
154
134
154
134
154
134
154
134
154
134
154
134
154
134
154
069
136
069
136
069
136
069
136
069
136
129
129
129
131
130
131
130
131
130
131
130
131
130
131
130
