4. Product Description
Meter Description
1. Low Alarm Alert (blue indicator)
2. High Alarm Alert (red indicator)
3. Backlit LCD
4. RCL (Recall MIN-MAX-AVG-DIF) and down arrow button
5. M (Mode) button
6. Battery compartment
7. Battery compartment screw
8. HI-LO (alarm) and up arrow button
9. Laser pointer lenses
10. IR measurement lens
11. Measurement trigger
12. Tripod mount
Display Description
Automatic measurement mode
Laser set to default ON
High/Low Alarm modes
Low battery
Scan mode (trigger pulled)
Measurement Data Hold
Units of measure for temperature
Primary measurement digits (center)
Maximum, Minimum, Average, Differential values
Emissivity setting
Secondary digits for MAX/MIN/AVG/DIF values (lower right)
2
IR320-en-GB_V1.0
6/18
