- Page 1 Hao-Hao Intelligent Pregnant Preparation Instrument Product Name: Comper Smart Fertility Tracker Product Model: BBTX COMPER...
-
Page 3: Table Of Contents
Content Basic Function and Working Principle Composition Safety Precautions Application Method Instructions for use Disinfection function Charging function Prompt function Voice Prompt Cleaning and maintenance Problems and Troubleshooting Storage and Shipping Condition Basic Parameters and Specifications The Registration Certificate Number and Production License Number Service Agencies and Information... -
Page 4: Basic Function And Working Principle
Basic Function and Working Principle Dear customers, Thank you for purchasing Comper Intelligent Pregnant Preparation Instrument (Product Name: Medical electronic thermometer, hereinafter referred to as Pregnant Preparation Instrument). For appropriate application of the product, please read the operating manual before using. Keep it safely after reading for reference. - Page 5 Composition Qualification Manual certificate Parts list: 1. One pregnant 4. One manual preparation instrument 5. One qualification certificate (thermometer) 6. “Hao-Hao Health” APP 2. One disinfection charging box 3. One USB charging cable...
- Page 6 particles Instruction of parts: 5. Disinfection charging box 1. Pregnant interface preparation instrument indicator 6. Charging indicator lamp 7. Contact-based charging 2. Heat probe connector 3. Contact-based 8. UV disinfection lamp charging interface 4. The anti-skid...
- Page 7 Safety Precautions In the Manual, all possible harms or damages caused by operation not according to instructions have been indicated and explained in accordance to the following classification. Please be aware and understanding that, for all death, injury or damage to goods due to operations not according to instructions specified in the Manual or deviating from the designed purpose of the product, the Company shall not bear any responsibility.
- Page 8 Warning: Keep the product out of the reach of infants and young children, and do not let it use the product alone. * If misused, there is the possibility of causing damages When the electronic device is limited in hospital or aircraft cabin, please do not turn on the product.
- Page 9 Do not vigorously bite the product. * May cause product breakdown. Please contact your physician if the condition of swallowing occurs. Do not place the product 22cm within the scope closely proximity to other medical instruments (such as heart pacemakers) Do not look directly at disinfection lamp * There is possibility of causing damage to eyes Caution:...
-
Page 10: Safety Precautions
Safety Precautions Do not place the product into boiling water for sterilization * There is possibility of causing damage to product breakdown or product failure. Dismantlement is prohibited. Do not dismount, dismantle or repair the product voluntarily. * There is possibility of causing serious body injury, measurement error and damages to the product Do not take out the magnet from disinfection charging box. -
Page 11: Application Method
Application Method Pregnant preparation instrument should be used with APP. 1. Download by scanning QR code. 2. Download from the application store: search “Hao-Hao Health” Note: Piggyback Bluetooth 4.0 and above module IOS7.0 and above operating system Piggyback Bluetooth 4.0 and above module Android 4.3 and above operating system... -
Page 13: Instructions For Use
Instructions for Use Note: The instrument should be charged for at least 3 hours in first use. 1. Open the Bluetooth of mobile phone. 2. Open the “Hao-Hao Health” APP and create an account. 3. Select device of “Hao-Hao Health Intelligent Pregnant Preparation Instrument”, and conduct subsequent operations according to APP tips. -
Page 14: Disinfection Function
Disinfection function When putting the pregnant preparation instrument back into disinfection charging box after measurement, pregnant preparation instrument will automatically shut down. Please connect with the power and close the disinfection charging box, the function of disinfection will turns on automatically. -
Page 15: Charging Function
Charging Function 1. Put the pregnant preparation instrument in the disinfection charging box. - Page 16 2. Insert the USB charging cable into the charging interface of disinfection charging box.
- Page 17 3. Lamp displays orange light when it is in charging. Lamp displays white light when charging is completed.
-
Page 19: Prompt Function
Prompt function Charging indicator lamp Long white light Charging is completed. Long orange light In charging Pregnant preparation instrument indicator lamp Long white light & one time of beep The main body turns on. Flicker white light Successful connection of Blueteeth. Long white light &... -
Page 20: Voice Prompt
Voice Prompt 1. One time of “beep” after measurement represents completion of measurement. 2. Three times of “beep” after measurement represent abnormal measurement temperature. -
Page 21: Cleaning And Maintenance
Cleaning and maintenance Please keep the cleaning of pregnant preparation instrument. Wipe the heat detector probe with a dry, soft cloth If there is a lot of dirt on the heat detector probe, please wipe the probe with a wringed cloth with neutral detergent or water, and then use a soft cloth to wipe it dry. -
Page 23: Problems And Troubleshooting
Problems and Troubleshooting Problem/failure Possible reason The measured value is too high due to Long white light & three times of beep activity or eating before measurement. The measured value is too low due to incorrect measurement position. The measured value is too low due to open mouth measurement. - Page 24 Adopted measures Please conduct measurement in bed immediately after waking up in the morning. Please conduct measurement in correct measurement position. Please close the lips during the measurement and do not breathe by mouth. Please conduct measurement according to correct instructions. Please use the product in the environment of +5 ˚C to +40˚C Please check whether the “Hao-Hao Health”...
-
Page 25: Storage And Shipping Condition
Storage and Shipping Condition Special storage Do not store the product in the following environments, or otherwise it will cause a breakdown or failure Humid environment High temperature, direct sunlight, dusty environment, or salt environment Environment with chemicals or corrosive gas Storage environment Temperature: -10°C to +40°C Humidity: ≤85% Ventilated room without corrosive gases... -
Page 26: Basic Parameters And Specifications
Basic Parameters and Specifications Model: BBTX Power of the product Battery: Rechargeable lithium battery (3.7 V) Battery life: continuous use of 12 hours, more than 300 times of charge-discharge Charging power supply: Micro USB (DC 5.0 V; 100 mA) (This product should be charged with the charging power supply of medical products comply with GB 9706.1/IEC 60601-1 for two MOPP insulation system. - Page 27 Working environment Temperature: + 5°C to + 40°C Humidity: ≤85% Atmospheric pressure: 70 to 101.3 kPa Product performance Sensor: Rapid response thermistor Measurement: High-speed precision Found Measuring range: 35.00°C to 42.00°C Accuracy: 35.00°C to 39.00°C, ± 0.05°C 39.1°C to 42.0°C, ± 0.1°C Measurement accuracy: 0.01 °C (displayed on the “Hao-Hao Health”...
-
Page 28: The Registration Certificate Number And Production License Number
Product registration certificate number: Product production license number: Service Agencies and Information Production company name: Comper (Beijing) Technology Co., Ltd. Manufacturer address: Floor 3 Unit 712, 713 Building 1, No. 3 Yongchang North Road, Economic and Technological Development Zone, Beijing Manufacturer Tel.: +86 01057480968... - Page 29 How the best is done Copyright Copyright is owned by Comper (Beijing) Technology Co., Ltd., the Company shall enjoy and reserve all exclusive authority of copyright. No part of the Manual shall be increased or decreased, excerpted, reproduced, altered or imitated without the prior written consent of the Company.
- Page 30 Federal Communications Commission (FCC) Statement 15.21 You are cautioned that changes or modifications not expressly approved by the part responsible for compliance could void the user’s authority to operate the equipment. 15.105(b) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules.
