All the reassurance you need
Fall Detector™
User Instructions
Activity
indicator
Belt /
clothing clip
D66070xx Issue A
Manual
trigger
button
Battery
Cover
Page 1 of 10

Advertisement

loading

Related Manuals for Tunstall Fall Detector

Summary of Contents for Tunstall Fall Detector

  • Page 1 All the reassurance you need Fall Detector™ User Instructions Activity indicator Manual trigger button Battery Cover Belt / clothing clip D66070xx Issue A Page 1 of 10...
  • Page 2 You can also use it to manually raise an alarm call. Wearing the fall detector • Clip the fall detector to your belt or clothing in the upright position shown in the drawing. It needs to be in the upright position to reduce the possibility of false activation.
  • Page 3 Automatic fall detection • Green light and two "beeps" indicates that the fall detector has been activated. • The fall detector will then monitor for between 6 and 15 seconds to verify if there could have been a fall. The green light will flash while it does this.
  • Page 4 All the reassurance you need Manual operation • Press the button on the fall detector to raise a manual alarm call. • The fall detector will "beep" and a red light indicates the fall detector is triggering an alarm call.
  • Page 5 All the reassurance you need • Remember, the fall detector will only detect you falling if you are wearing it. • The fall detector must be worn at or above the waist, where it will detect the maximum number of falls.
  • Page 6 It is able to automatically generate an alarm call when low battery is detected. • If it is necessary for you to change the battery, the fall detector uses a 6 volt Duracell PX28L battery. • To access the battery, remove the battery cover screw and then the battery cover by sliding it in the direction of the arrow.
  • Page 7 (no lights will show and no buzzer will sound). • Replace the sliding cover and the screw. Test the fall detector by making a manual call. Inform the operator that you are making a battery test call.
  • Page 8 • It is recommended that you test the fall detector once a month: • Make a manual test call. • Tap the fall detector when it is lying down. After 5 Seconds the fall detector should beep and the green light start to flash.
  • Page 9 All the reassurance you need Radio Approval Notices Australia The Fall Detector operates on a frequency of 312MHz and is certified approved by TRL Compliance to AS/NZS 4268:2003 Canada Canadian Certification Approvals Number IC: 1231A-66004A Federal Communications Commission (FCC) notices...
  • Page 10 All the reassurance you need Battery Replacement Guide Battery Inserted Date Battery Replacement Date Month Year Month Year Remember to change the battery once a year. D66070xx Issue A Page 10 of 10...
