Memorex 8188RF User Manual

Wireless smart office keyboard & mouse kit
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
8188RF
Wireless Smart Office Keyboard & Mouse Kit
User's Guide
Version 1.0
Created August 29, 2002

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 8188RF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Memorex 8188RF

Summary of Contents for Memorex 8188RF

  • Page 1 8188RF Wireless Smart Office Keyboard & Mouse Kit User’s Guide Version 1.0 Created August 29, 2002...
  • Page 2 The information in this document is subject to change without notice and does not represent a commitment on the part of the vendor. No warranty of representation, either expressed or implied, is made with respect to the quality, accuracy or fitness for any particular purpose of this document.

  • Page 3: Table Of Contents

    Table of Contents Introduction....................1 What's in this package ................1 System Requirements ................3 Hardware Installation ................4 Software Installation ..................9 Uninstallation.....................10 Smart Office Keyboard Driver ..............11 6.1 To Pop Up “KeyMaestro” Dialogue Box........11 6.2 To Pop Up “Configure Button” Dialogue Box.......13 Using the Keyboard .................15 7.1 Office Application Keys Block ............15...

  • Page 5: Introduction

    1 Introduction Congratulations on your purchase of the wireless USB smart Office keyboard and mouse kit! This keyboard and mouse kit will finally free you of the constraints of your desktop by providing a wireless connection between the keyboard or mouse and your PC. Pass around the keyboard or mouse during meetings without having to bother about a cable blocking your way or write e-mails and surf the Internet from the comfort of your living room couch!
  • Page 6 A driver disc Batteries (4pcs of AA alkaline batteries)

  • Page 7: System Requirements

    2 System Requirements Microsoft Windows 98, Windows ME, Windows 2000 or Windows XP operating system Microsoft Internet Explorer 5.0 or later version (for the Internet keys) CD-ROM or DVD drive (for CD or Video operation) Standard sound card (for CD or Video operation) USB port Microsoft...

  • Page 8: Hardware Installation

    Hardware Installation Slide Switch Setting Step 1: Make sure your PC is switched off. Step 2: Take the receiver and select channel CH1 or CH2 by using the slide switch on the back of the receiver. (Remember your selection.) Bottom View of Slide Switch Setting of Receiver Step 3: Connect the receiver to your PC by plugging in the receiver’s USB connector into your PC.
  • Page 9 Channel Switch ID Button Bottom View...
  • Page 10 Step 5: Use the slide switch on the back of the keyboard to select the same channel as the one selected in step 2 on the receiver. Slide Switch Setting Step 6: Take the mouse and make sure the batteries on the back are installed correctly.
  • Page 11 ID Setting This keyboard kits contains 2 channels and each channel contains 256 sets ID. This extra ID-recognition function helps to protect against interference from other RF keyboards in the same environment. After completing the hardware installation you must set the ID’s of the receiver, mouse and keyboard.
  • Page 12 Remarks: You must follow the procedure above to set the ID of receiver, mouse and keyboard. Once the receiver ID button is pressed you have 35 seconds to complete the entire process, or you will need to begin again. Once the keyboard and mouse USB connectors are plugged in the yellow receiver light will flash.

  • Page 13: Software Installation

    Software Installation After completing the hardware installation and turning the PC power on you will have immediate access to the alpha-numeric keys of the keyboard. In order to utilize the specialty keys you must first install the keyboard driver using the CD included in the box. To install the keyboard driver: Step 1 : Remove any existing keyboard software from the computer.

  • Page 14: Uninstallation

    Uninstallation Please note that you have to uninstall the driver first if you want to reinstall the driver. To uninstall the keyboard driver: Right-click the driver icon and select "Exit" command to exit Step 1: the driver program. Click "Start" menu (on the left-bottom taskbar). Step 2: Move cursor to "Programs"...

  • Page 15: Smart Office Keyboard Driver

    Smart Office Keyboard Driver To Pop Up “KeyMaestro” Dialogue Box Use left-click of the mouse on the Smart Office Keyboard Driver ico on the taskbar, a “KeyMaestro” dialogue box will pop up with the following functions.  6.1.1 Select a HotKey This function contains the default function of a key.
  • Page 16 Auto play function. The default of this function is enabled.

  • Page 17: To Pop Up "Configure Button" Dialogue Box

    To Pop Up “Configure Button” Dialogue Box 6.2.1 Label In the Label box, type the name of application that the button will launch, or any name that will help remember the function of the button. This label will appear on screen each time you press the button.
  • Page 18 how to solve your problem.

  • Page 19: Using The Keyboard

    Using the Keyboard 7.1 Office Application Keys Block Word Open Microsoft Word. Excel Open Microsoft Excel. PowerPoint Open Microsoft PowerPoint. Calendar Open “Calendar” function of Microsoft Outlook. 7.2 Internet Keys Block Back Return to the last page you viewed. Forward View the next page you viewed before.
  • Page 20 Note: If “Log Off” key function cannot work properly, see “Troubleshooting” for more information.

  • Page 21: Multimedia Keys Block

    7.4 Multimedia Keys Block Mute Mute the sound. Volume up Adjust the volume up. Volume Adjust the volume down. down Stop Stop the playing. Skip backward to the previous file/track Previous when pressing once. Skip forward to the next file/track when Next pressing once.
  • Page 22 F3: Open Open or finds a file in program. save the active file with current file name, location F4: Save and file format. Search for and replaces the specified text and F5: Replace formatting. Start the spelling check program in the active F6: Spell document.
  • Page 23 functions of embedded office keys. So, some enhanced functions are only for target language usage. The descriptions of the enhanced office keys’ functions are for reference and may not reflect your keyboard exactly.

  • Page 24: Clipboard Keys Block

    7.6 Clipboard Keys Block...
  • Page 25 1. Works as a mouse with scrolling functions in 2 directions - up and down. You can use the up and down functions of the Scroll Wheel to scroll the document horizontally. 2. Works as a mouse button. When you push on the scroll wheel, a series functions dialogue will pop-up as below.
  • Page 26 Remove the selection from the active document. Copy Copy the selection to the Clipboard. Paste the previously cut or copied items from Paste the Clipboard. Press on the mark key once and use the up, down, right and left direction keys to select items.

  • Page 27: Using The Mouse

    Using the Mouse 8.1 Using the Mouse Driver After installing the mouse driver as described in Chapter 4 you will be able to start up the Mouse Control Panel by left double-clicking on the KeyMaestro Mouse icon in the Windows task bar. This should appear after restarting your machine.
  • Page 28 Orientation folder: allows you to setup the angle of the mouse when moving upwards.

  • Page 29: The Definition Of Mouse Extra Function

    8.2 The Definition of Mouse Extra Function: Function Definition Let you to open 8 special functions quickly. For the Quick Jump detailed, please refer to the ”Quick Jump Function Introduction” in next section. Replace the "double click" movement to activate an Double Click application or function, it can save the valuable mouse- clicks.

  • Page 30: Quick Jump Function Introduction

    8.3 Quick Jump Function Introduction Also, after installing the mouse driver and invoking the KeyMaestro mouse driver program you will have access to 9 special function icons by pressing the scroll wheel once. These 9 functions are: Mouse Control PanelActivate the Mouse Control Panel Menu. Control Panel Activate the “Control Panel”...
  • Page 31 and select Help.

  • Page 32: Troubleshooting

    Troubleshooting If you are experiencing problems with your keyboard, please check the following: 1. Keyboard & Mouse do not work properly Please re member to set the ID when your keyboard kits do not work properly. 2. Mouse does not work accurately Use the mouse only on a clean, flat, non-slippery surface in order to ensure smooth and accurate cursor action.
  • Page 33 7. Word, Excel, PowerPoint, Calendar cannot do action, but the onscreen can show up Please make sure you have installed the Office Applications completely. If Office Applications are not fully installed, those keys can only see the onscreen display and do not work. 8.
  • Page 34 replace Office 97, or use IE 5.0 to replace IE 4.0.
  • Page 35 Frequently Asked Questions (FAQ). Memorex Products One Year Limited Warranty. Memorex Products, Inc. will replace this product free of charge if it is found to be defective in materials or workmanship during normal usage conditions for a period of one year from date of purchase (proof of purchase required).
  • Page 37 封底內頁 FCC GUIDELINES This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions may cause harmful interference to radio communications.
