M-system M2EXV Operating Manual page 8

• Parameters
MODE ITEM SETTING PARAMETER
Basic setting 01
11
12
13
14
15
16
17
18
19
20
21
22
26
RANGE
Lockout setting Lock / Unlock
Input range 0 – 50mA
-1000 – +1000mV
-10 – +10V
0 % input setting 0.00 – 48.00
-1000.0 – 900.0
-10.000 – 9.000
100 % input setting 2.00 – 50.00
-900.0 – 1000.0
-9.000 – 10.000
0 % input scaling -99999 – 999999
100 % input scaling -99999 – 999999
Input decimal point No decimal point
The number of decimal
places : 1 – 5,
Output range 0 – 20mA
-5 – +5V
-10 – +10V
0 % output setting 0.000 – 19.000
-5.000 – 4.750
-10.000 – 9.000
100 % output setting 1.000 – 20.000
-4.750 – 5.000
-9.000 – 10.000
0 % output scaling -99999 – 999999
100 % output scaling -99999 – 999999
Output decimal point No decimal point
The number of decimal
places : 1 – 5,
Loop test -5.00 – 105.00
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: + 81 ( 6 ) 6659-8201 Fax: + 81 ( 6 ) 6659-8510 E-mail: info@m-system.co.jp
UNIT INITIAL VALUE
— Lock
— 0 – 50mA
mA 4.00
mV
V
mA 20.00
mV
V
— 0.00
— 100.00
— 2 places of decimals
— 0 – 20mA
mA 4.000
V
V
mA 20.000
V
V
— 0.00
— 100.00
— 2 places of decimals
% Cancel
EM-5133-B Rev1 P. 8 / 18
