Vista Simplicity Cellular Shades TDBU Quick Start Manual

Simplicity
V
Rechargeable Motorization
ist a
CELLULAR SHADES – TDBU | Quick Start Guide
Your shade has come pre-programmed from the factory. Follow these easy steps to get started.
Rail No.
Connect
Channel
Connect
External Battery for shades under 36'' wide
1. Connect the motor and battery 2. Mount the shade. 3. Your shade is now ready! Select the
in the headrail (as shown). programmed channel, then the rail, and use the
UP and DOWN arrows to operate the shade.
Setting/Using a Favorite Position
NOTE: Make sure there is only one shade programmed to the channel when setting a favorite position.
If more than one shade is set, please see UNLINK A SHADE in the Simplicity guide at vistaproducts.com/guides.
1. Using the UP and DOWN arrows, 2. To save the Favorite position; 3. Press the STOP/FAVORITE button to
position Rail No. 1 and Rail No. 2 select Rail No. 3, then hold the LIMIT button move the shade to the set Favorite position.
and the UP button at the same time. Make sure shade is fully stopped
to the desired Favorite position.
NOTE:
Release after a series of short beeps. before using the Favorite position.
For more in depth motorization programming instructions, please visit vistaproducts.com/guides
