Vista AUTOMATE ARC Quick Start Manual

Tubular motor

Advertisement

AUTOMATE
V
ist a

1. Mount the shade.

1. Remove the battery cover
from the back of the remote.
Quick Start Guide
2. Wake up the shade by holding P1 (approx. 2 seconds),
until shade jogs 1x and beeps 1 long beep.

LOCK/UNLOCK THE REMOTE

2. Hold the LOCK button until...
For more in depth motorization programming instructions, please visit vistaproducts.com/guides
ARC Tubular Motor
Hold P1
A)
Lock
A) If 15 channel remote:
- To Lock: ...hold until the 'U' on the screen turns into an 'L'.
- To Unlock: ...hold until the 'L' on the screen turns into an 'U'.
B) If single channel remote:
- To Lock: ...hold until the blue light is solid
- To Unlock: ...hold until the blue light blinks
3. Your shade is now ready!
Use the UP and DOWN arrows to operate
the shade. If using a 15 channel remote,
first select the programmed channel.
B)
Blue Light

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AUTOMATE ARC and is the answer not in the manual?

Questions and answers

Summary of Contents for Vista AUTOMATE ARC

  • Page 1 AUTOMATE ™ ARC Tubular Motor ist a Quick Start Guide Hold P1 1. Mount the shade. 2. Wake up the shade by holding P1 (approx. 2 seconds), 3. Your shade is now ready! until shade jogs 1x and beeps 1 long beep. Use the UP and DOWN arrows to operate the shade.
  • Page 2 Adjusting Upper and Lower Limits The upper and lower limits have been set at the factory. NOTE: The remote must be unlocked before adjusting the limits. Adjusting limits needs to be done with a hand held remote; a wall switch remote may not be used. When adjusting one shade, any other shades on the same channel need to be temporarily unlinked from the remote.
