- Page 1 B350M GRAVITY FEED FOOD SLICER INSTALLATION, USE, MAINTENANCE & PARTS MANUAL REVISED MAY 2011 MARBLEHEAD, OHIO 43440-2099 U.S.A. Ph. 419-798-4451 Fax 419-798-9106 sales@birosaw.com service@birosaw.com http://www.birosaw.com...
- Page 23 Electrical Box Assembly Mono-Phase 220V-50Hz Z9MSB Cleaning stone Z9TCA Mono phase card 115V-60Hz Z9SCH Single phase card 220V-50Hz X0090 : B300M G111-A : B350M-B350A-B350MV Water-ring protection B300M : M9346 UP S/N 90764 G7CIN FROM S/N 90765 Z9PIE Foot B350 M :...
-
Page 24: Complete Assembly
BIRO B 350 M Manual Slicer May 2011 G257 X0560 Z9PIE G119C Z8BCN G122 G0170 Complete Assembly F9331500 W6CUS X0270 G102 G9361 Z8BCN G110 X0290 CODE DESCRIPTION Q,TY F9331500 SPRING d 10 L 55 G0170 ROD - INDEX SLIDE G102... - Page 25 BIRO B 350 M Manual Slicer UPTO S/N 80415 G9362 C2091 G0160A G0124 F9321500 C2041 G0122 C2080 G127 C2032 C2080 X0630 G118 X0490 G103 Z9MBP CODE DESCRIPTION Q,TY C2032 MEAT GRIP HOLDER C2041 MEAT GRIP C2080 BUSHING C2091 HANDLE ASSY...
- Page 26 BIRO B 350 M Manual Slicer May 2011 G9362 Complete Assembly G0160A C2091 C2041 G0124 C2080 F9321500 G0122 C2032 G127 C2080 G118 G280 G121 Z8MBPA STARTING WITH S/N 11113 CODE DESCRIPTION Q,TY C2032 MEAT GRIP HOLDER C2041 MEAT GRIP C2080...
- Page 27 BIRO B 350 M Manual Slicer May 2011 G200 COMPLETE ASSEMBLY X0210 X0272 W7CUS X0230 X0250 X0271 Z9BCR X0520 X0240 G116 X0110 G114 G104 X0120 G113 Z9BCR Z9FUN X0260 CODE DESCRIPTION Q.TY G104 CARRIAGE G113 SHAFT - PIVOT RETURN G114...
- Page 28 BIRO B 350 M Manual Slicer UPTO S/N 80415 G101 G105 G111 X0491 ZZVOL X0360 G125 Z3ATQ Z5L4G G120 G100 G117 G9364 G112 Z8MGR G124 X0080 Z9GHI X0280 CODE DESCRIPTION Q.TY G100 FRAME G101 GAUGE PLATE G105 RING STUDBOLT G111...
- Page 29 BIRO B 350 M Manual Slicer May 2011 STARTING WITH S/N 11113 G105B G101 G111-B G111-A X0491 X0360 X0620A Z3ATQ G125 Z5L3G G120 G100 G1171 G9364 G112 Z8MGRA G134 X0080 Z9GHI X0280 CODE DESCRIPTION Q.TY G100 FRAME G101 GAUGE PLATE...
-
Page 30: Motor Assembly
BIRO B350 M Manual Slicer May 2011 W2CUS G109 G106 G5CIN UP S/N 80415 G108 W2CUS M9314 M9315 X0070 X0060 G8CIN FROM S/N 80416 Motor Assembly W6CUS A62GM 115V/60Hz W6CUS IP65 M9313 M9310 115/60 Hz M9372 115V/60 Hz IP65 UP S/N 80415... - Page 31 BIRO B 350 M Manual Slicer May 2011 X0720 Z9TCA 115V-60Hz X0710 W3CON Z9PLA Start Switch Illuminated Z9PLH Stop Switch GRSTA MONO-PHASE 115V-60Hz Complete Assembly CODE DESCRIPTION Q.TY GRSTA COMPLETE CONTROL BOX W3CON CAPACITOR 20 Mf X0710 ELECTRIC BOX - BASE...
- Page 32 BIRO B 350 M Manual Slicer UP S/N 80415 AF008 AF01US Z9MSB AF006 AF033 AF011 Z9MAF AF008 AF023 AF022 ZZVOL AF006 AF0020 AF038 AF022 AF034 Complete Assembly AF039 AF035 AF036 AF040 AF022 AF039 AF038 CODE DESCRIPTION DESCRIZIONE Q.TY AF006 SHAFT - SHARP + CLEANING STONE...
- Page 33 PROTECTION B350 M / B350 A AF070 PROTECTION B350 MV AF07200 PIN B300 M AF07201 PIN B350 MV AF07203 PIN B350M / B350 A AF07301 LOCKING SHAFT B350 MV AF07302 LOCKING SHAFT B300 M AF07303 LOCKING SHAFT B350 M / B350 A AF074...
- Page 34 BIRO B350 M Manual Slicer May 2011 AF021 AF025 CODE DESCRIPTION Q.TY AF021 KNOB Ø40 M10 AF025 PLASTIC WHEEL...
