Mechanical Controls
T20000R Series
60 Amp Pool/Spa Control Panels
The T20000R Series Control Panels features an all-weather enclosure and contain a
mechanism. The circuit breaker base accepts interchangeable type breakers made
by a several manufacturers. In addition, the enclosure has provision for installing
additional switches or GFCI receptacles on the side and inside.
Applications:
Specifications:
Enclosure: 0.048 in. steel with electrostatically applied light beige finish
16 3 ⁄ in. (42.6 cm) H x 8 7 ⁄ in. (22.5 cm) W x 4
4 8
Knockouts: Five combination
1
combination ⁄ – ⁄ in. on the left side, one
1 3
2 4
1 ⁄ x 2 ⁄ in. knockout on the right side for mounting switches or GFCI
3 3
4 4
Panel Rating: 60 Amp, 120, 240 VAC or 120, 208 VAC; Single Phase, 60 Hz
Time Switch Rating: 30 Amp Resistive/Inductive, Tungsten or 1000 VA Pilot Duty
each pole, 120, 208, 240 VAC; 2 HP (24 FLA), 120 VAC; 5 HP (28 FLA), 240 VAC
Shipping Weight: See table
Agency Approval: CSA/C-US
Model # Description/Mechanism
T21000R Enclosure only
T21001R T101M
T21004R T104M
T20004R* T104M
* T20004R has a limited availability, T21004R is the replacement model.
For additional trippers ( 1 ON 1 OFF per pack ), Order No. 156T1978A.
For additional OFF trippers (25 OFF per pack), order No. PA115.
For stand-offs for décor knockouts (4 stand-offs per pack), order No. 21T156A.
Note: See page 130 for a detailed list of replacement mechanisms.
www.intermatic.com
3 ⁄ in. (11.1 cm) D
8
⁄ – ⁄ in. and three ⁄ – 1 in. on the bottom, one
3 3
2 4 4
⁄ – 1 in. on the back and one combination
3
4
Clock Supply
Switch Volts AC, 60 Hz
None NA
SPST 120
DPST 240
DPST 240
Shipping Weight
11.2 lbs (5.0 kg)
12.2 lbs (5.5 kg)
12.2 lbs (5.5 kg)
11.6 lbs (5.3 kg)
T21000R
T21004R
T20004R
