Electrical Harness Connections - Evinrude E-Tec 40 HP Service Manual

ELECTRICAL AND IGNITION

ELECTRICAL HARNESS CONNECTIONS

ELECTRICAL HARNESS
CONNECTIONS
Inspect wiring and electric al connectio ns. Disas-
semble a nd clean all corrode
Replace damaged wiring, con nectors, o r termi-
nals. Repair any shorted electrical circuit s. Refer
to wiring d iagrams and reference charts f or spe-
cific wiring details.
Refer to CONNECTOR SERVICING on p. 116.
Engine Harness to Stator
Connector
Pin
Description of Circuit
No.
1 Stator winding (yellow)
2 Stator winding (yellow)
3 Stator winding (orange)
4 Stator winding (orange)
5 Stator winding (brown)
6 Stator winding (brown)
92
EMM J1-A Connector
d co nnections.
Pin
No.
002025
10
11
12
Wire Color
13
Yellow/White
14
Yellow
15
Orange/White
16
Orange
17
Brown/White
18
Brown
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
Description of Circuit
1 vacant
2 Diagnostic connector
3 Diagnostic connector
4 vacant
5 vacant
6 Crankshaft position sensor (CPS)
7 Ground, CPS (digital)
8 Bootstrap connector (programming)
9 Stop circuit
Throttle position sensor (TPS) 5 V
vacant
vacant
CANbus, NET-L
CANbus, NET-H
12 V to EMM (fused)
Tachometer
CHECK ENGINE signal, SystemCheck
TPS
Engine temperature sensor
Air temperature sensor
CANbus, NET-S
CANbus, NET-C
vacant
LOW OIL signal, SystemCheck
WATER TEMP signal, SystemCheck
TPS ground (analog)
Engine temp. sensor ground (analog)
Switched B+ to EMM
LOW OIL switch
vacant
vacant
Neutral switch (shift linkage)
vacant
vacant
001875
Wire Color
Red
White
Yellow
White
Blk/Orange
Blk/Yellow
Red
Blue
White
Red/Purple
Gray
Tan/Orange
Green
Pink/Black
Pink/Blue
Red
Black
Tan/Black
Tan
Black
Black
Purple
Tan/Black
Yellow/Red
