Simplicity 755M Parts Manual page 5

Handles and Controls Group
REF NO. PART NO.
1 1668525
2 1669323
3 1916621
4 1715132
5 1722636
6 1722638
7 1676954
8 1918447
9 1666255
10 1916622
11 1916964
12 1960252
13 1720238
14 1668524
15 1720240
16 1715123
17 1918452
18 1668185
19 1924361
20 1668523
21 1921159
22 1921319
23 172038
24 1722627
25 1667588
26 1714084
27 1960093
28 1919438
29 1919326
30 1722633
31 1722690
32 1960519
33 1722630
34 1921962
35 1722667
36 1923358
37 1715655
38 1722637
39 1922837
40 1715654
41 1960556
42 1921221
43 1722631
44 1920397
45 1715658
46 1720452
47 1917356
48 1922127
49 1715659
50 1921332
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693980 555M, 5HP Manual Start
1693981 555M, 5HP Manual Start (Exp.)
1693982 755M, 7HP Manual Start (Exp.)
1693983 755E, 7HP Electric Start
TP-400-2561-00-IW-S
QTY.
2 ROD, Control, Lower
2 SPRING, Extension
4 NUT, Hex, #10-24 R.H.
1 CLUTCH ROD, Auger Drive
1 HANDLE, R.H. (Auger Control side)
1 LEVER, Auger Clutch, R.H.
2 GRIP, Black Vinyl, for 1Ó Tube
3 PIN, Cotter
1 ROD, Shift, Lower
3 NUT, Hex Hd., 1/4-20
3 LOCKWASHER, Spring
2 CARRIAGE BOLT, 1/4-20 x 5/8 G5
1 ROD, Shift, Upper
2 BLOCK, Pivot
1 ROD & ARM ASMY, Pivot
1 SPRING, Torsion
2 PIN, Cotter
2 BUSHING
1 WASHER
1 ROD & CLEVIS ASSY.
1 CAPSCREW, Hex Hd., 1/4-20 x 2-1/4
3 WASHER, Flat 1/4
1 KNOB, Internal Thread, 3/8-16
1 DASHBOARD & SUPPORT ASSAMBLY
4 BUSHING, Nylon
1 KNOB, Chute Control Spinner
1 NUT, Push, 3/8
4 NUT, Hex Lock ESNA Light, 5/16-18
2 WASHER, Flat 5/16
1 ROD & SPRING ASSEMBLY
1 SPRING, Compression
1 NUT, Push for 1/2" Stud
1 ROD, Free hand Control
1 CAPSCREW, Hex Head, 1/2-20 x 1 3/4
1 LEVER, L.H. (Traction Drive Clutch)
3 NUT, Hex, Centerlock, 1/4-20
2 SPACER, Large
1 HANDLE, L.H. (Traction Drive Control side)
2 CAPSCREW, Hex Hd., 1/4-20 x 1-1/2
2 SPACER, Small
2 CAPSCREW, Taptite, Pan Hd., Torx, 1/4-20 x 3/4
4 CAPSCREW, Hex Hd. 5/16-18 x 1-1/2
1 LEVER, Pivot
2 NUT, Hex Lock ESNA Light, 1/4-20
1 ROD, Chute Control
2 CLAMP, Tube, Saddle
5 LOCKWASHER, 5/16
2 CAPSCREW, Hex Hd. 5/16-18 x 1 3/4
1 CLUTCH ROD, Traction Drive
2 CAPSCREW, Hex Hd. 5/16-18 x 3/4
DESCRIPTION
3
