P RTS LIST
16
1. Filter media inlet plug (order code 5786)
2. Filter media inlet
3. Filter lid (order code 5787)
4. Filter lid O ring - not shown (order code 5788)
5. Water inlet 90° elbow hosetail assembly (order code 5789)
6. Water inlet
7. Water outlet
8. Water outlet fitting (order code 5798)
9. Water outlet pipe assembly (order code 5791)
10. Spare hosetail (order code 5792)
11. Sponge (order code 5793)
12. Water inlet pipe assembly inc flow inductor (order code 5794)
13. Media chamber
14. Diffuser bowl
15 Hanging bracket (order code 5795)
16. Hanger securing screw (order code 5796)
5
6
1
2
3
15
11
13
14
2
10
7
8
12
9
