HSE03
Voice Siren

Installation Instructions

General Introduction
The HSE03 Voice Siren is a two-way wireless alarm device which functions
not only as a siren, but also a strobe light with voice indicator functions. Its
great compatibility with our U-Net family security products makes it suitable for
smart home cloud based platforms such as Homesys.
HSE03 includes the following functions:
* Tamperproof protection
* Green and red flashing strobe light
* Visual and audible alarm indications
* 6 indicating beep sounds for identification
* EEPROM for non-volatile memory facility
* LED for identification, visual command confirmation and battery status

Product Layout

Figure 1 Front View
Figure 3 Back View
Figure 2 Under View
Figure 4 Inside View
Keys
A. Speaker
B. Voice Speaker
C. Backplate screws
D. Backplate
Functions
A. Siren Speaker
B. Voice Speaker
E. Tamper Jumper Link
F. Learning Key
G. Micro USB
H. DC Jack
Binding with Homesys
1. Loosen and remove the locking screw from the bottom edge of the unit
counter clockwise.
2. Slide the backplate out of the unit.
3. Prepare four 1.5V alkaline batteries. Do not insert them into the unit yet.
4. Log into the Homesys account from a web browser.
1
E. Tamper Switch
F. Learning Key
G. Micro USB (Factory use only)
H. DC Jack
Siren Warning 110 dB
Voice Indicator 90 dB
A full alarm condition will be enabled when the device is
removed from the wall.
Learn and clear ID codes.
Update voice messages through the USB cable. (Factory
use only)
Socket for connecting DC adapter
