EVERSPRING SE132 Manual

Premier EZ Security Alarm System
WHAT YOU GET
The EZ Security Alarm system should contain the following components:
1 x EZ Alarm with Dialer (SE132)
1 x Wireless Motion Detector (SP101)
1 x Door/Window Contact Detector (SM101)
1 x Remote Controller (SR132)
4 x 1.5V AA size Battery (SE132)
2 x 1.5V AAA size Battery (SP101)
2 x 3V CR2032 Lithium Battery (SM101, SR132)
User's manual and fixing pack
INTRODUCTION
It is designed to protect your property, serving as a basic alarm system and entry
enunciator as well. Upon receipt of radio signal from the associated transmitters,
a piercing 110 decibels alarm sound or chime alert will be emitted and in the
Telephone Jack
Battery Cover
meantime dial up the preset phone numbers by playing 6 seconds alarm message
for help.
LOADING THE BATTERY
The EZ Alarm requires 4 "AA" batteries. If the
every 3 seconds, the batteries need to be replaced right away, otherwise the Alarm
cannot be working properly. Average battery life for stand-by usage is 8 months,
subject to alkaline batteries being applied.
To install the batteries:
1. Open the battery cover. (FIGURE 1)
2. Insert 4 "AA" batteries ensuring correct polarity being put. (FIGURE 1)
3. Refit the battery cover.
Note: Remove batteries before storing the Alarm for extended periods. Batteries
corrode over time and may cause permanent damage to the unit. Different types
of batteries or new and used batteries should not be mixed. Depleted batteries
should be removed from the unit and disposed of properly.
CONNECTING TO THE TELEPHONE LINE
To call for help when the Alarm is activated, plug one end of the telephone line to
wall outlet and the other end into the side of the Alarm. (FIGURE 2)
1
LED of Alarm is flashing once
FIGURE 1
