Page 1: Installation Manual
Installation Manual PAX TECHNOLOGY LIMITED... - Page 2 Room 2416, 24F., Sun Hung Kai Centre, 30 Harbour Road, Wanchai, Hong Kong Tel: +852-2588-8808 Fax: +852-2802-3300 Email: dainel@pax.com.hk Website: www.pax.com.hk...
- Page 3 PAX TECHNOLOGY LIMITED Figure 1: Front view Figure 2: Back view...
- Page 4 Figure 3: View from all angles...
- Page 5 Afterwards, lock the mount with the card inside and replace the cover. 2) Device Connection Figure 6: Connecting the IM700 to an IM300 unit...
- Page 6 Figure 6. The IM300 both controls and powers the IM700. Note that the upper right RJ45 port on the IM300 is reserved for the use of the IM700, do not connect the IM700 through the other ports. 1) Switching the device on and off...
- Page 7 PAX TECHNOLOGY LIMITED 3) LED indicators The different LED indicators show the following states for the IM700: ○ All LEDs being in the off state means that the device is unpowered or powering up and connecting to a terminal. ○...
- Page 8 2) Make sure the terminals the USB or RJ45 cables connect to provide the appropriate voltages at the proper pins. 3) Do not insert unknown materials into any port on the IM700, this may cause serious damage to the device.
- Page 9 PAX TECHNOLOGY LIMITED interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 10 This device meets the government’s requirements for exposure to radio waves. This device is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Government.
