Symbol IEEE 802.11A/B Hardware Quick Reference Manual page 9

2. Rubber feet (4)
3. Metal mounting bracket
4. # 10 wall screws (2)
5.
# 10 wall anchors (2)
6. Installation Guide
Item number Item
Ceiling Mounting Hardware
Metal mounting bracket
7.
T-bar clips (2)
8.
Plastic mounting bracket
9.
# 10 nuts (2)
10.
# 10 screws (2)
11.
# 10 washers (4)
12.
13. Extended light pipe
Mounting Hardware Wall, Desk
- 9 -Model 5030 Access Port Quick Reference Guide DRAFT V3
Apply to bottom of Access Port only on
desk mounted installations
Below ceiling and wall bracket are the
same. Bracket is packaged with Access
Port and not with mounting kit hardware
items.
Sheet metal self-tapping for use with
provided anchors (if needed).
Notes
Same as wall bracket. Bracket
is packaged with Access Port
and not with mounting kit
hardware items.
Below ceiling installations only.
Includes two clip sections,
carriage bolt and wing nut for
each T-bar clip.
Above ceiling installations only.
Bracket is packaged with
Access Port and not with
mounting kit hardware items.
For use with above ceiling
installation
For use with above ceiling
installation
For use with above ceiling
installation
For use with above ceiling.
installation
