Symbol IEEE 802.11A/B Hardware Quick Reference Manual page 8

Display of AP exploded view and wall mounting hardware identified by item numbers.
Symbol does not recommend mounting the Access Port directly (above or
Caution!
below) to any suspended ceiling tile with a thickness less than ½ an inch or a
suspended ceiling tile with an unsupported span greater than 26 inches.
Symbol recommends that the Access Port be fitted with a customer supplied
Safety Cable suitable for the specific installation. The safety cable should be
steel at least .06 - .10 inches in diameter similar to cable used to support T-
bar in a suspended ceiling installation.
Mounting hardware included is identical for all Access Port configurations. Verify that the contents
of the box includes the correct Access Port purchased and mounting hardware:
Item
number Item
Access Port Assembly
1.
WSAP-5030-100-WW
WSAP-5030-200-WW
WSAP-5030-201-WW
- 8 -Model 5030 Access Port Quick Reference Guide DRAFT V3
Notes
The Access Port configuration with
external antenna connectors does not
come with external antennas.
802.11a with external radio RSMA
antenna connectors (antenna is a
separate purchasable item).
802.11a/b configuration external RSMA
(.11a radio), BNC (.11b radio) antenna
connectors (antenna is a separate
purchasable item).
802.11a/b configuration internal
antennas.
