Twin Disc Unit - Sumo Mixidisc Operator's Manual And Parts List

6.1 Twin Disc Unit

8
7
ITEM
PART NO.
NO.
SW391 (R/H. Not
1 Shown) & SW390
(L/H)
2 SW107
3 SWB103
4 SWM1235CHSQ
5 SWM12005
6 SWB102
7 SW101
8 SWB101
9 SWM3004
10 SWM30001
11 SW103
12 SW102
13 SW108
14 SWM16004
15 SWM16001
16 SWM16120
17 SW1153
18 SW646
19 SWB184
20 SWM1240CHSQ
5
4
3
DESCRIPTION QTY.
Disc Arm 1
Clamp Plate 1
Rubber 4
M12 x 35 Cup
10
Head Square
M12 Flanged
10
Nut
Bearing 1
Twin Disc Axle 1
20" Scalloped
2
Disc
M30 Nylock
1
Nut
M30 Washer 1
Dust Cover
and Convexed 1
Disc
Dust Cover
and
1
Concaved
Disc
Disc Axle
1
Washer
M16 Nylock
2
Nut
M16 Washer 2
M16 x 120 Bolt 2
M16 Washer
2
(Thick)
Disc Scraper 1
18" Scalloped
Disc (end of
1
disc row, Not
Shown)
M12 x 40 Cup
2
Head Square
2
1
16
15
12
6 14
DO NOT SCALE DRAWING
Sumo Mixidisc
MACHINE/COMPONENT:
TITLE:
Twin Disc Unit Assembly
SCALE 1:20
REVISION:
10
13
11
20 18
17
Drawings and design information found
herein remain the sole property of Sumo
UK Ltd. Reproductions may only be
made with the permission of the owner.
DATE: 09/06/14 DATE: INITIAL: TW
9
