Summary of Contents for Belkin F5U115-UNV
- Page 1 USB SCSI Adapter with Termpower F5U115-UNV P73417-A...
-
Page 2: Introduction And System Requirements
If you own a non-iMac ™ machine, such as a PowerMac or G3, and wish to add USB ports, please obtain a Belkin USB BusPort for Mac (model # F5U005-MAC). ™... - Page 3 Note: Optional AC Adapter may be purchased directly from Belkin. Ask for part #F5U115xPWR. MACINTOSH 1. Insert the Belkin USB SCSI Adapter Installation CD into your CD-ROM drive. 2. Double-click on the CD icon that appears on the Mac OS desktop.
- Page 4 (or Hub), it must first be plugged into a SCSI device that provides termination power before Windows will detect and enumerate the Adapter and the SCSI device(s). If your SCSI device(s) does not provide termination power, contact Belkin to purchase the optional AC Adapter (part# F5U115xPWR).
- Page 5 “Next”. 5. Windows will now prompt you for drivers. Insert the Belkin USB SCSI Adapter CD-ROM in your CD-ROM drive. Put a check mark in the box named “Specify a location:”. Type D:\PC Driver. (In this example, D is the driver letter for the CD-ROM drive;...
- Page 6 2. Connect the USB SCSI Adapter to the computer or an attached hub with a USB A-B Cable. 3. Windows will detect the device as "Belkin USB SCSI Adapter" and launch the Add New Hardware Wizard. Click “Next”. Windows ®...
- Page 7 (typically D:\WIN2000). If you prefer you may click on the "Browse" button and browse to the "WIN2000" directory of the installation CD-ROM. Click “OK.” 7. Windows will locate the drivers for "Belkin USB SCSI Adapter." Click “Next”. Windows ®...
-
Page 8: Troubleshooting
Adapter’s operation. If you are just connecting one device and that device does not have termination power, contact Belkin to purchase the optional AC Adapter (part# F5U115xPWR). The SCSI device(s) must be powered up AND connected to the Adapter prior to plugging into the USB port. - Page 9 F2N982-XX SPECIAL F2N984-XX F2N983-XX SPECIAL This is only a partial listing of our most common SCSI Cable Assemblies. Contact your Belkin sales representative for assistance in choosing the cable you need. To uninstall the USB SCSI Adapter, do the following:...
-
Page 10: Compatibility List
Compatibility List A. Devices that work Standalone SCSI Hard Drives • Seagate ST31220A - 2GB • Seagate ST51080N - 1GB • Microtech P-E-2000 - 2GB SCSI Removable Media Drives • Coniglio MO 230MB ( FujitsuDrive M2512A ) • Fujitsu 640 Dyna MO - M2513A - F/W: 1300 •... - Page 11 Compatibility List (continued) • SCSI - Panasonic PD device - LF 1000 • SyQuest SQ270 - 270MB SCSI CDD\CDR\CD Changers • Sony 4X - CDU 76S SCSI CDD F/W 1.0a. • NAKAMICHI 4-tray CD Changer - MJ 4.8 • NEC Multispin 4x - 7-tray CD Changer - NRC MBR - 7.4 •...
-
Page 12: Fcc Statement
Belkin Components warrants this product against defects in materials and workmanship for its lifetime. If a defect is discovered, Belkin will, at its option, repair or replace the product at no charge provided it is returned during the warranty period, with transportation charges prepaid, to the authorized Belkin dealer from whom you purchased the product. - Page 13 Diamantlaan 8 • 2132 WV Hoofddorp • The Netherlands Tel: +31 (0) 235698765 Fax: +31 (0) 235612694 Tech Support • Tel: +31 (0) 235698765 e-mail: eurosupport@belkin.com © 2000 Belkin Components. All rights reserved. All trade names are registered trademarks of respective manufacturers listed.
